Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment
Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment
T panel multi-electrode longitudinal welder machine adopts double arc double wire single pool of carbon dioxide gas shielded high speed welding, welding speed can reach 0.85m/min, this machine can use 16-24 sets of OTC 600A welding power to weld 4-6 assembled longitudinal at the same time, match with seam tracking device and original imported welding smoke concentrate recovery & purification devices.
|
Welding way |
Double arc double wire single pool or single arc singl wire single pool carbon dioxide gas shielded welding |
|
Welding method |
Flat fillet welding two surfaces at the same time |
|
Bulb steel size |
220*10-450*35mm |
|
Angle steel |
250*100*9mm-600*200*13.5mm |
|
T-bar |
300*10/ 100 *17-850*11.5/ 300*25 mm |
|
Distance between longitudinal |
650-950 mm |
|
Longitudinal length |
4000-25000mm |
|
Welding speed |
200-900mm/min |
|
Welding current&voltage control type |
Centralized control |
|
Welding seam track way |
Auto-electronic tracking |
|
Welding smoke dedusting way |
Centralized dedusting |
