Full Automatic Horizontal Metal Band Sawing Machine Double Column

Full Automatic Horizontal Metal Band Sawing Machine Double Column

1. Main Feature

a. Metal cutting including stainless steel, alloy, tube, square metals, H beam, Channel and others
b. Hydraulic control the vice clamp
c. PLC control the operation to be high precision
d. Passed CE, ISO9001, SGS
e. Can rotate 0-45 degree
f. Auto feeding and cutting, hold clamping device

2. Main specification

a. Max. cutting capacity
● 90°: 500*700 mm
● 45°: 500*500mm
● 30°: 500*550mm

b. Saw blade
● Speed: 18-80 frequency converter step less speed
● Size: 1.3*41*5750mm
● Tension: hydraulic
● Cleaning: wire brush and flood coolant

c. Motor output
● Saw blade: 4Kw
● Hydraulic: 1.5Kw
● Coolant

d. Feeding
● Length: 400
● Mode: manual

e. Machine weight: 3500kg

f. Vice control: hydraulic

g. Machine size: 3160*1750*2180

f. Machine accessories
● Machine tool box
● Feeder table
● Wire brush
● Operation instruction
● One piece of saw blade
