Roller Type Manual H Beam Shot Blasting Machine Sand Blasting Machine

Price Negotiable
Price: USD1500
MOQ: 1
Delivery Time: 15 working days
Brand: Friendship Machinery
Product Description

Roller Type Manual H Beam Shot Blasting Machine Sand Blasting Machine



1. Products features



    The machine is available mould and roller sandblasting machine, Class products can batch production small workpiece with roller to improve manufacturing output, Heavy workpiece can use turntable to reduce the labor intensity, Fully meet the customer's requirements.





2. Main technical parameters



Model FSM-1010 Roller type sand blasting machine
Internal size 1000*1000*790mm
Complete machine size 1000*1540*1830mm
Power 220V 50HZ
Machine floodlight 220V 13W LED lamp
Separator motor 220V 50HZ 550W
Separator air volume 8.5m3/min
Compressed air source 2-8bar (kg/cm2)
Turntable diameter 500mm
Turntable bearing 150kg
Roller bearing 10-30Kg
Machine net weight 380kg
