Super Industrial Safety Cabinets Dangerous Goods Cabinets Used In Lab Or Hospital
Super Industrial Safety Cabinets Dangerous Goods Cabinets Used In Lab Or Hospital
1. Introduction
According to international practice, there are four colors of common used materials storage safety cabinet to store various hazardous materials.
Generally, the yellow cabinets are used for storing flammable materials, the red for combustible materials, the blue for weak corrosive materials (Strongly corrosive materials can only be stored inPP(polypropylene) material storage cabinet, such as sulfuric acid, nitric acid, hydrofluoric acid and other strongly corrosive materials), and the white are used for storing the toxic materials.
The color is for distinguishing different type materials in storage and convenient using. The common effect of the each type safety cabinet is for fire prevention, heat insulation and secure storage.
2. Specification
| Model | FSM-4-CS | FSM-12-CS | FSM-30-CS | FSM-45-CS | FSM-60-CS | BK-90-CS |
| Capacity |
4 gallon (15L) |
12gallon (45L) |
30gallon (113L) |
45gallon (170L) |
60gallon (226L) |
90gallon (340L) |
|
Selective colors |
Yellow, blue, red, white (not available for PP material cabinet) |
|||||
| Steel plate | Thickness over 1.0cm | |||||
| Insulation layer | Thickness 38cm | |||||
| Storage container | Height 50cm | |||||
| Door | Single | Single | Double | Double | Double | Double |
| Material | Cold-rolled steel with epoxy paint, PP | |||||
| Shelf | 1 | 1 | 1 | 2 | 2 | 2 |
|
External size (H *W*D) |
56*43*43cm | 89*59*46cm | 112*109*40cm | 165*109*46cm |
165*86 *86cm |
165*109 *86cm |
|
Package size (H*W*D) |
76*58*58 cm |
109*74*61 cm |
132*124*55 cm |
185*124*61 cm |
185*101*101 cm |
185*124*101 cm |
| N.W. | 30KG | 60KG | 100KG | 138KG | 165KG | 190KG |
| G.W. | 40KG | 75KG | 120KG | 169KG | 190KG | 225KG |
