3 Roller Hydraulic Symmetrical Plate Rolling Machine For Shipbuilding / Petroleum
1. Main Summarize
W11Y-6×6000 3 roller hydraulic symmetrical plate rolling machine, suit to bend mild steel thickness not more than 6mm when it’s width is 6000mm under the normal temperature condition; if use it to bend mild steel width less than 6000mm, it can to bend thicker mild steel, but the accurate bend thickness should to calculate; and if use it to bend other kinds steel sheet with different yielding limit, the max thickness should to do calculation.
W11Y-series device widely used in manufacturing industries for example boiler, shipbuilding, petroleum, chemical, cement and motor and so on.
W11Y-series device with compacted structure, easy to operate, and widely selected by users in actual production.
2. Technical parameters
| Model | Unit | W11Y-6×6000 |
| Yielding limit of bended sheet | Mpa | σs≤245 |
| Maximum bended thickness | mm | 6 |
| Maximum bended width | mm | 6000 |
| Diameter of up roller | mm | Φ330 |
| Diameter of bottom rollers | mm | Φ200 |
| Distance between two bottom rollers | mm | 320 |
| Minimum diameter when full load | mm | Φ650 |
| Rolling speed | m/min | About 4 |
| Lifting speed of up roller | mm/min | About 120 |
| Support roller | / | 3 sets * 4 |
| Main motor power | KW | 11 |
| Hydraulic motor power | KW |
5.5 |
| Total weight | kg | 17000 |
| Overall dimension | mm | 8500×1500×2000 |
