Gantry type street pole welding machine for wind tower production line

Price Negotiable
Price: Negotiable
MOQ: 1
Delivery Time: 30 working days
Brand: FSM
Product Description

1. Technical parameter



No. Item Specification
1 Machine width 3000mm
2 Rail length 15000mm
3 Diameter of high mast 300-1800mm
4 Length of high mast 12000mm
5 Welding wire diameter 3.2-5mm
6 Welding wire speed 250-1200mm/min
7 Power 10KW (excluding welder power)
8 Dimension 2830*4450*3695mm





2. Supply range



● Travel motor: YDS100-4 low speed motor



● Lifting motor: SCWS-08 deceleration machine



● Flux recycle system: flux recovery machine, power bucket, pipe



● Submerged arc welder: MZ1000



● Welding ground wire 140mm2: 32m



● Welding arm: arc guide device, welding gun



● 7 sets cable movement pulley, 10# I beam (15m), 24kg rail (15m * 2)



● Control panel, electric box
