Steel Plate Electro Shearing Hydraulic Press Brake DELEM DA66T Controller
Steel Plate Electro Hydraulic Press Brake Machine, Hydraulic Shearing and Prss Brake for Plate
1. The main character and use of the device
● This machine is widely used in light industry, aviation, shipbuilding, metallurgy, instrument, electrical appliances, stainless steel products, construction and decoration industry, especially suitable for urban construction, highway light pole, power pole, car girder work-piece processing and manufacturing, etc.
● This series hydraulic press brake machine, adopts steel weld structure; vibration aging to release stress, the device with good rigidity and stability; the whole frame with good rigidity, work is stable, safety and reliable, easy to operate.
● To adopts DA66T controller specialized used in CNC press brake machine from DELEM company, and adopts electro-hydraulic scale servo valve from BOSCH company, Germany, so the system work is stable, and with high make accuracy. On the system installed grating, electro-hydraulic scale valve, and electronic amplifier of valve to make a closed circle control system, thus inspect and control the relative location and synchronous accuracy between ram and worktable precisely, let the ram keep synchronous running, and assure the press brake depth and angle.
2. Technical parameters
| Model | Units | WE67K-250T/4100 | |
| Nominal pressure | kN | 2500 | |
| Worktable length | mm | 4100 | |
| Distance between uprights | mm | 3120 | |
| Throat depth | mm | 400 | |
| Ram stroke | mm | 250 | |
| Max opening height | mm | 540 | |
| Ram speed | Unloaded | mm/s | 60 |
| Full-loaded | mm/s | 8 | |
| Return | mm/s | 70 | |
| Gear pump | Model | / | CP1-63-P-10R |
| Flow | L/min | 63 | |
| Pressure | Mpa | 31.5 | |
| Working Pressure of hydraulic system | Mpa | 26 | |
| Main motor power | kW | 18.5 | |
| Quantity of control axial | / | 3+1 (Y1,Y2,X1,V) | |
| Control system | / | DA66T (DELEM, Netherland) | |
| The Net weight | kg | 15600 | |
| The overall dimension | mm | 4200×2100×3100 | |
Back side view
