QC11Y-6x3200 Hydraulic Guillotine Shearing Machine , NC Hydraulic Swing Shearing Machine
Price:
Negotiable
MOQ:
1
Delivery Time:
30 days
Brand:
FRIENDSHIP MACHINERY
Product Description
QC11Y-8*3200 NC Guillotine Shearing Machine
1. Technical parameters
| Model | Unit | QC11Y-8*3200 | |
| Controller | / | E21S | |
| Maximum shear thickness | mm | 8 | |
| Maximum shear width | mm | 3200 | |
| Sheared steel sheet strength | N/mm2 | 450 | |
| Shearing angle | ° | 0.5-2 | |
| Times of strokes | per/mm | 12-30 | |
| Blade length | mm | 3200 | |
| Distance between vertical columns | mm | 3300 | |
| Back gauge range | mm | 20-600 | |
| Throat depth | mm | 100 | |
| Work table height | mm | 800 | |
| Main motor power | KW | 11 | |
| Gear pump | Model | / | CP0-20-P-10R |
| Flow | ml/r | 20. | |
| Pressure | Mpa | 31.5 | |
| Electrical system | V/Hz | 3P, 380V, 50HZ | |
| Net weight | kg | 7700 | |
| Overall dimension | mm | 3800*1700*2100 | |
2.Main components manufacturer
| Component name | Specification | ||
| Blade | Material | 6CrW2Si | |
| Manufacturer | Shanghai Shangpin Blade Producing Co., Ltd. | ||
| Main Motor | Type | Y type | |
| Manufacturer | Jiangsu Hengli | ||
| Main electric components | Siemens | ||
| CNC controller | Type | E21S | |
| Manufacturer | Estun automation co., ltd. | ||
| Hydraulic system | Pump | Type | Gear pump |
| Manufacturer | HIGH-TECH Fluid Power Co., Ltd. | ||
| Valve | HaiMen Xinli | ||
| Seals | VALQUA, Japan | ||
