10x3200 NC Hydraulic Shearing Machine Swing Type Electric Controller System
Price:
Negotiable
MOQ:
1
Delivery Time:
30 working days
Brand:
FRIENDSHIP MACHINERY
Product Description
10x3200 NC Hydraulic Shearing Machine Swing Type Electric Controller System
1. Overview
● Hydraulic drive, swing beam, return of knife is smooth and prompt by accumulator nitrogen cylinder. All steel welded structure, vibrating treatment of ageing for removal of internal stress, with good rigidity stability
● The stroke and frequency of shearing can be controlled; the machine has the function of single
shearing and automatic continuous shearing.
2. Technical parameters
| Model | Unit | QC12Y-6*4000 | |
| Controller | / | E21S | |
| Maximum shear thickness | mm |
6 for carbon steel 4 for stainless steel |
|
| Maximum shear width | mm | 4000 | |
| Sheared steel sheet strength | N/mm2 | 450 | |
| Shearing angle | ° | 1.5 | |
| Times of strokes | per/mm | 15 | |
| Blade length | mm | 4100 | |
| Distance between vertical columns | mm | 4125 | |
| Back gauge range | mm | 20-600 | |
| Work table height | mm | 760 | |
| Main motor power | kW | 7.5 | |
|
Axial plunger pump |
Model | / | 25MCY14-1B |
| Flow | ml/r | 25 | |
| Pressure | Mpa | 31.5 | |
| Electrical system | V/Hz | 3P, 380V, 50HZ | |
| Net weight | kg | 7500 | |
| Overall dimension | mm | 4170*1800*1700 | |
3. Design, make, inspect standards
● JB 8781-1998
● JB/T 5197-1998
● GB/T 14404-1993
