E21 NC 2500mm Sheet Metal Hydraulic Press Brake For WC67Y 160T Steel Plate
E21 NC 2500mm Sheet Metal Bending Tools , 160T Steel Plate Press Brake For Hydraulic Press
1. Technical parameters
| Model | Units | WC67Y-160T/2500 | |
| Bended steel sheet strength | N/mm2 | 450 | |
| Nominal pressure | kN | 1600 | |
| Worktable length | mm | 2500 | |
| Dstance between uprights | mm | 2020 | |
| Throat depth | mm | 400 | |
| Ram stroke | mm | 200 | |
| Maximum opening height | mm | 470 | |
| Gear pump | Model | / | CP0-25-P-10R |
| Flow | L/min | 25 | |
| Pressure | MPa | 31.5 | |
|
Ram speed |
Unloaded | mm/s | 60 |
| Work | mm/s | 8 | |
| Return | mm/s | 70 | |
| Working pressure of hydraulic system | Mpa | 26 | |
| Main motor power | KW | 11 | |
2. The main features of E21 numerical control device
● E21 press brake numerical control device from Estun automation co., ltd.
● Positioning control of back gauge.
● Intelligent positioning control.
● One-side and two-side positioning which Eliminates spindle clearance effectively.
● Retract functions.
● Automatic reference searching.
● One-key parameter backup and restore.
● Fast position indexing.
● 40 programs storage space, each program has 25 steps.
● Power-off protection.
● Work-piece count.
● Pressure-holding and unloading time setting.
● Millimeters/ inches.
● Chinese/ English language.
