High Tech QC11Y Guillotine NC Shearing Machine And Press Brake For Steel Plate
High Tech QC11Y Guillotine NC Shearing Machine And Press Brake For Steel Plate
1. Technical parameters
| Model | Unit | QC11Y-12×3200 |
| The maximum shear thickness | mm | 12 |
| The maximum shear width | mm | 3200 |
| The sheared steel sheet strength | N/mm2 | 450 |
| Shearing angle | ° | 0.5-2 |
| The strokes | min-1 | 8-25 |
| The blade length | mm | 3300 |
| The distance between uprights | mm | 3430 |
| The back gauge range | mm | 20-600 |
| Main motor power | KW | 18.5 |
2. The device structure and character
● Adopts three points roll guides, to release clearance between guides, higher cut quality.
● Installed a hand wheel on the front of device, rotate it to adjust cutting edge clearance, client
should to adjust it by different thickness.
● Up blade adopter adopts falling-in type, easy to blank, and can to higher cut accuracy.
● With the performance to section cut.
● Electric controller system: EC21S
3. Overview
● This device suit to shear various material by different need, main suit to shipbuilding, car made, steel made, switch appliance, contain made, machinery made and light manufacturing and so on. As the major support of shipbuilding and equipment made, and replacement of large hydraulic guillotine shearing machine in time, to suit new requirement, that is very important.
