CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
Price:
Negotiable
MOQ:
1
Delivery Time:
25 working days
Brand:
Friendship Machinery
Product Description
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
1. Standard equipment
- Estun E21NC control System
- Powered Depth Y-axis&Back gauge X-axis
- DELTA Inverter controlled back gauge
- HIWIN Ball screws & Polished rod with 0,05mm accuracy.
- Plate Support Arms
- Germany Bosch-Rexroth Hydraulic
- Germany EMB Tubing connector
- Germany Siemens Main Motor
- Tele mecanique/Schneider Electrics
- Hydraulic &Electrical overload protection
- Top and Bottom Tooling(86°,R0.6mm)
- Safety Standards(2006/42/EC)
2. Technical parameters
| Model | Units | WC67Y-125T/2500 | |
| Maximum bended thickness | mm |
8(σs≤245), 5(σs≤345) |
|
| Nominal pressure | kN | 1250 | |
| Worktable length | mm | 2500 | |
| Distance between uprights | mm | 2020 | |
| Throat depth | mm | 320 | |
| Ram stroke | mm | 120 | |
| Maximum opening height | mm | 385 | |
| Gear pump | Model | / | CP0-25-P-10R |
| Flow | L/min | 25 | |
| Pressure | MPa | 31.5 | |
| Ram speed | Unloaded | mm/s | 45 |
| Work | mm/s | 6 | |
| Return | mm/s | 55 | |
