CNC Hydraulic Press Brake With Delem Controller DA69T CNC System

CNC Hydraulic Press Brake With Delem Controller DA69T CNC System

Press Brake Machine and Shearing Machine

Hydrauilc tandem press brake

1. All steel welded structure, integrated treatment (vibration aging, heat treatment) heating to eliminate stress, have good rigidity and stability

2. Heat treatment of the rack, rigidity optimization verification on entire machine and the application of hydraulic compensation structure jointly ensure the bending precision of MB8 series Press Brakes.

3. Programming a product simply consists of introducing the characteristics of the material to be bent,the dimensions of the product and the necessary tooling & die.The optimizing software searches for the best bending cycle.

4. Rear block distance, upper stroke, electric adjustment, manual fine adjustment device, digital display.

5. Imports including linear transducer,pressure proportional valve and servo motor.

6. Ram stroke(Y1,Y2) and backgauge(X,R,Z) are controlled by controller automatically,high productivity.

7. Adopting Electro-hydraulic proportional servo synchronization. Optional point within stroke can be controlled.Repeat precision of Y axes: ±0.01mm, Parallism: 0.02mm. Strong ability of deviation resistance.

8. Backgauge adopts ball-bearing screw and rolling guideway,quick speed and high repeat positioning precision.X axes with resolution 0.1mm.
