Automatic H Beam Welding Line 14mm Equipment 600mm/Min

Flat Steel Plate Longitudinal Joint Butt Welding Machine Automatic For Marine

Flat steel plate Welding Machine

Automatic Flat Butt Welding Equipment

Metal MIG Welding Machine

Steel butt welding machine

1. Technical parameter

● Effective steel plate width: 6000mm
● Effective steel plate thickness: 6-14mm
● Steel plate length: 12000mm
● Suitable welding wire diameter: 3.2-5mm
● Main machine welding speed: 300-600mm/min
● Flux automatically feed and recycle
● Total power: 6KW (exclude welder)
● Dimension: 8200*3250*2850mm

2. Supply range

● Main framework, water cooling copper block, steel plate position and aligning device, steel plate end lift device, flux recycle system, steel plate press device.
● Hydraulic system, electrical system.
● SAW welder: 1 set submerged arc welder (non inverter model).
● Conveyor framework, roller, reducer, drag chain (produce by buyer, seller provide the drawings, please see the structure showing).

3. Spare parts

● Socket head wrench 8mm: 1 piece
● General wrench 10 inch: 1 piece
● SAW welding tip: 10 pieces

(main structure layout)
