Weatherproof IP68 High resolution Side view vehicle mounted cameras in 700 tvl
Weatherproof IP68 High resolution Side view vehicle mounted cameras in 700 tvl with metal or plastic case optional
1.Product Name:With metal housing CM03 Weatherproof Side view vehicle mounted camera in 700 tvl
2.Basic Info
|
Brand Name: |
RECODA |
|
Model Number: |
CM03 |
|
Certification: |
ROHS/FCC |
|
Place of Origin: |
China |
3. Product Quick Details
|
Product Name |
Waterproof Side view night vision IR Car Camera |
Application |
In vehicle |
|
Sensor |
CCD |
Resolution |
420tvl,480,600tvl,700tvl |
|
IR distance: |
10m |
Feature |
Waterproof |
|
Type |
Analog Camera |
Lens |
6.0/3.6/2.8mm optional |
4.Business Term
|
Minimum Order Quantity: |
1 pcs |
|
Price: |
negotiation |
|
Payment Terms: |
T/T , Paypal or western Union |
|
Supply Ability: |
3,000pcs per month |
|
Delivery Time: |
3~5 working days after received your payment |
|
Packaging Details: |
1 piece to a box, 56 PCS packed in a carton |
Specifications:
|
Model |
CM03 |
|
Pick up Device |
1/3 SONY CCD |
|
TV System |
NTSC / PAL |
|
Picture Elements |
512 x 582 pixels / 512 x 492 pixels |
|
Horizontal Resolution |
420 TVL / 480 TVL / 600 TVL / 700TVL optional |
|
Sensitivity |
0 Lux at F1.2 (Infrared LED On) |
|
Scanning System |
2: 1 Interlace |
|
Synchronization |
Internal |
|
Infrared Spectrum |
850nm |
|
S/N Ratio |
Better than 48 dB, (AGC Off) |
|
Infrared LED |
9 LEDs |
|
Infrared LED Range |
10m |
|
Video Output |
1 Vp-p, 75Ω composite, BNC x1 |
|
Audio Output |
N/A |
|
Mirror |
Adjustable |
|
Gamma Ratio |
0.45 |
|
Lens Angle |
120 degree |
|
Lens |
3.6mm Standard ( with 2.8 and 6.0mm optional ) |
|
Pan Adjusting |
0-360° |
|
Tilt Adjusting |
0-40° |
|
Out-casing Material |
Aluminum Alloy / Metal optional |
|
Power Supply |
12V DC ± 10%, ø 2.1mm DC Jack |
|
Power Consumption |
Max. 180mA |
|
Dimensions (LX W X H) |
83 (L) ×60 (w) ×55 (H) mm |
|
Net Weight |
250g |
|
Weatherproof/Water Proof |
IP68 |
|
Operating Temperature |
-20°C~70°C , RH95%MAX |
|
Color |
Black, White, Silver |
Description:
Lens: 2.5mm
.Lens Angle: 120°
.Infrared LED light: 9 PCS
.IR Distance: 10 m
.Waterproof Rate:IP68
.Shell material: aluminum alloy
.Bracket material: nylon fabric
.Dustproof, waterproof, hydrochloric acid prevention, explosion prevention
.Current Consumption: Max. 180mA
.Power Supply: DC12V
.Operating Temperature: -20°C~70°C , RH95%MAX
.Storage Temperature: -40°C~80°C,RH95%MAX
Applications:
- Buses, Coach, Logistic Trucks, Tractors, Police Cars, Taxi
- Armored cars, Public security and law enforcement vehicles
- Ambulances, Traffic duty vehicles and other fields.
Competitive Advantage:
.Chip CMOS & Chip SONY optional
.Mic: collects the environmental sound around the camera
.Rear,Celling Mount ,left,Right view optional
Self heating: The cameras will entry the self-heating mode when the
environmental working temperature is lower than -5°C. And it wills automatic stop heating
when the temperature reaches 30°C
Waterproof Side view night vision IR Car Camera (Metal Shell )
