IR Day & Night Vehicle Mounted Cameras Weatherproof 2.0 Megapixel Rear View C801 RECODA
IR Day & Night Vehicle Mounted Cameras Weatherproof 2.0 Megapixel Rear View C801 RECODA
Main Features:
100% Brand New and High Quality
Waterproof design for outdoor use. Easy and Convenient to use
High quality AHD (Analog High Definition ) Color camera,Using the latest CMOS technology
Using common 75-3 coaxial cable to carry out as far as 500 meters HD video without any video signal loss
Specification:
| Model | AHD200M-RV1A |
| Pick up Device | 1/3 CMOS Aptina 0230 |
| TV System | NTSC |
| Picture Elements | 1280(H)*1080(V) |
| Effective pixels | 2.0M pixels |
| Day-night mode | External control (default) / Auto / color / black and white |
| Infrared Spectrum | 850nm |
| S/N Ratio | More than 72 dB, (AGC Off) |
| Auto Gain Control | Auto |
| White Balance | Auto |
| Electronic Shutter | AUTO/ 1/50(1/60)-1/100,000sec |
| Back Light Compensation | Auto |
| Infrared LED | 18 LEDs |
| Infrared LED Range | 8 m |
| Video output | 1 Vp-p, 75ΩComposite, BNC x1 |
| Audio Output | N/A |
| OSD Control | Available |
| Power Consumption | 210mA |
| Lens | Standard f3.6mm Fixed Megapixel Lens |
| Lens Mount | M12XP0.5mm Thread |
| Tilt Adjusting | 0-90° |
| Video footage to take up space | 1H ≈ 1.506 GB |
| Power Supply | 12V DC ±10% |
| Dimensions(L x W x H) | W76 x H78 x D69 mm |
| Net Weight | 280g |
| Weatherproof | IP67 |
| Operating Temperature | -20°C to +50°C |
| *Specifications are subject to change without prior notice. | |
Simple Operation instructions:
(1) Press OSD for 5 seconds, the module system will be switched from PAL to NTSC (default is PAL),
Repeat the operation again, the system will switch from PAL to NTSC;
(2) The output of the module signal is switched from AHD to CVBS (default output is AHD) by OSD 5 seconds.;
(3) Press OSD right for 5 seconds, the module signal output will be switched from AHD to CVBS;
(4) By determining the key, other settings may be made.
Packing list:
Camera 1
Instruction Manual 1
Self Drilling Screw 2
Mounting Plug 2
Hey-key 1
Optional Lens select-able from f 2.8mm to f 12mm
