92kw Deutz Engine 3200kg Front End Wheel Loader
3200kg Capacity Front End Wheel Loader With 92kw Deutz Engine
3200kg Capacity Heavy Construction Machinery , Front End Wheel Loader With 92kw Deutz Engine
Specifications
- Condition: New
- Brand Name: Laurel
- Model Number: LC933
- Place of Origin: Guangzhou, China (Mainland)
- Type: Front Loader
- Moving Type: Wheel Loader
- Dimension(Long * Breadth * High):7300x2200x3070mm
- Rated Load: 3000kg
- Certification: CE,EPA,ISO
- Warranty: 12 months
- After-sales Service Provided: Overseas third-party support available
- Engine: Yunnei/Weichai/Deutz
- Rated power: 92kw
- Bucket capacity: 1.5-1.7cbm
- Overall weight: 6500kg-7000kg
- Wheelbase: 2600mm
- Color: Yellow
- Maximum dump height (mm): 3300
Packaging Details: Nude package, 1 pc/20GP, 2 pcs/40HQ
Delivery Detail: Shipped in 28 days after payment
Our advantages:
High quality
Reasonable price
Strict delivery time
Good after-sales service
Profession maker for 36 years
Gold supplier 9th year
Strict quality control
The features of the machine
1. Equipped with Deutz Engine, optional Weichai Engine, Yunnei, Dongfeng Cummins
2. High quality self-made hydraulic gearbox and driving axle.
3. Choose best hydraulic components, pilot operation, easy and durable.
4. Strong and durable frame, have the automatic flat function in high place.
5. (Quick change )option attachment:wooden fork, pallet fork, grass fork, rock bucket, bigger bucket, snow bucket, mixing bucket etc.
6. Changeable luxurious meter, back camera, more comfortable for driving.
7. High pressure and safer air assist disc brake braking system
8. According to clients request, customize higher dumping and longer arm products.
Technical parameters:
| Specification: | |
| Overall weight(kg) | 8000-8500 |
| L×W×H(mm) | 7300x2200x3070 |
| Rated bucket capacity(m³) | 1.5-1.7 |
| Rated load(kg) | 3000-3200 |
| Maximum dump height (mm) | 3200/3500 |
| Bucket indicator | Yes |
| Max. breakout force(KN) | 48.8KN |
| Transmission System: | |
| Model of torque converter | YJ280 or YJ320 |
| Type | Single grade three components |
| Gearbox type | Fixed-spindle power shift |
| Gear shift | 2 gear ahead,2 gear astern or 4 gear ahead,2 gear astern |
| Engine Details: | |
| Stander Model | Weichai or DEUTZ engine |
| Optional Model | LOVOL(EURO3)/CUMMINS engine |
| Type | In-line arrangement, direct injection, Water cooling, 4 stroke, 6 cylinder |
| Rated power(kw) | 92kw |
| Rated speed(r/min) | 2200-2300 |
| Hydraulic system: | |
| Distribution of work valve | DF20.2C |
| Working pump | CBF18 |
| Steering system: | |
| Type | Articulated hydraulic steering |
| Max. turning angle | 35±1° |
| Brake system: | |
| Brake type | Air assisted oil disc on four wheel |
| Tire: | |
| Standard tire | 16/70-24 or 17.5-25 |
| Packaging Details: | Nude package,1 unit in 1x20GP,2units in 1x40GP |
| Delivery term: | 15-30 days after received the deposit |
| Warranty: | 15 months after delivery. |
