Big Heavy Construction Machinery , 5 Ton SEM Type 656D 656G Compact Wheel Loader

Main performance parameters of Wheel Loader 656G 656D

I: Performance:

rated load:5000kg

overall weight:17100kg

rated bucket capacity:3 cbm

maximum tractive force:172KN

maximum breakout force:≥162KN

maximum grade ability:30℃

maximum dump height:3200mm

maximum dump reach:1260mm

overall dimension (L×W×H):8247×3060×3410mm

minimum turning radius:6000mm

II: Engine

Model:Weichai Steyr WD10G210E22

Engine type:lnline water cooling dry cylinder injection

No. of cylinder-bore/stroke:6－126×130mm

rated power:162kw--2400r/min

maximum torque:920N.m

min fuel-consume ratio:≤215g/kw.h

III: Transmission system

torque converter:YJ375

gearbox mode:Power shift normally engaged straight gear

gear shift:4 forward shift 4reverse shift

maximum speed:38km/h

IV: Drive axles

main reducing spiral:bevel gear grade 1 reduction

decelerating mode:planetary reduction, grade I

wheel base (mm):3300mm

wheel tread:1800mm

minimum ground clearance:450mm

V: Hydraulic system

system working pressure:18Mpa

boom lifting time:5.95±0.2s

total time:10.95±0.5s

fuel tank capacity:300L

function of leveling automatically:Yes

VI: Brake system

service brake:air over hydraulic disc brake on 4 wheels

parking brake:manual parking brake

VII: Tyre

tyre specification:23.5-25

front tyre pressure:0.4Mpa

rear tyre pressure:0.35Mpa
