Pro Furniture Testing Machines , Chair Seats Front Stability Testing Equipment
Price:
USD 7,000-10,000 per set
MOQ:
1 set
Delivery Time:
20 working days
Brand:
HTI
Product Description
Chair Seats Front Stability Testing Machine Furniture Testing Machines
Description:
This machine is suitable to test the seats (such as chairs, office chairs) front stability.
Principle:
Put the test-piece on the test table, blocked the front leg, apply specified force with forward 20N applied at seat loading point, check the article tends to overturn forward or not to determine the test-piece forward stability performance.
Technical parameter:
| Model | TNJ-023 |
| Power | Electonic |
| Seat surface loading Max | 600N |
| Horizontal force | 20N |
| Loading point position | seat surface center position,60mm from front edge |
| Seat surface loading pad | dia:200mm, camber surface:R300mm,9 pins |
| Weights basket lifting | manual control |
| Dimensions(WxDxH) | 100x140x105cm |
| Weight | 500kg |
| Air source | 6kgf/cm2 stable air source |
| Seat impatct testing | office chair impact test |
| Standard | EN 1022,EN 1729-2 and ANSI/BIFMA X5.1 12.4 Front Stability |
