3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V
3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V
3 way solenoid valve has 3 ports and 2 switching states (open or closed) and are electromechanically controlled. With 3 ports and 2 switching states, the valve can be either NC (normally closed), NO (normally open), mixing, distributing or universal. NC is most common: the valve has 1 input, 1 output, and an exhaust port. The output connects to exhaust with no power, and with power the input is connected to the output moving the media. They can also be designed as normally open (power to close) or bi-stable (latching). It is important to first select the housing material of your valve to ensure it is suitable for the media that the valve will be controlling.
Technical Data of Solenoid Valve:
|
Port Size (inch) |
Orifice Size (mm) |
Kv Value (m³/h) |
Pressure Range | Body Material | Seal Material | Dimension | ||
| A | F | K | ||||||
| 3 Way Normally Closed, Direct Acting | ||||||||
| 1/8'' | 1.5 | 0.05 | 0 to 16 bar |
Brass Stainless Steel |
NBR: -10 to +80℃ EPDM: -30 to +120℃ FKM: -30 to +150℃ |
40 | 25 | 81 |
| 2 | 0.12 | 0 to 10 bar | 40 | 25 | 81 | |||
| 1/4'' | 1.5 | 0.05 | 0 to 16 bar | 40 | 25 | 84 | ||
| 2 | 0.12 | 0 to 10 bar | 40 | 25 | 84 | |||
