factory sale cheapest price 46 metric tons buried bulk lpg gas storage tanks, ASME underground lpg gas tank for propane

Item

Parameters

Product name

46 metric tons bulk LPG storage tanker

Trademark

CLW

Product model

CLW3200-115

Overall dimension(L*W*H)

mm

13620*3436*4026

Tanker dimension(inter diameter*thickness*length

mm

DN3200*20*12300

Full volume

m3

115

Curb mass

kg

23901

Working pressure

Mpa

≤1.62

Working temperature

℃

≤50

The tanker material adopts Q345r, the tanker thickness is 18mm, the thickness of the head is 20mm. the safety valve model is A42F-2.5-80(pressure when open is 1.69Mpa); the loading medium is LPG (Propane), the medium density is 442kg/m3. And the tanker will be with the Flammable and explosive identification.

“CLW” brand LPG storage tanker manufactured by Chengli Special Automobile Co., Ltd. adopts scientific leading treatments, assuring the lowest Shrinkage and highest
dimension stability at the low temperature.  The advantages of the LPG storage tanker are low-temperature storage, easy transporting, safe and reliable, easy maintain, etc. The LPG storage tankers are suitable for storing LPG, liquid ammonia, carbon disulfide, epoxyethane, gasoline, butane, propane, propene, etc.

All the LPG tank trucks and LPG pressure vessels manufactured by Chengli Special Automobile Co., Ltd. are line with the GB150-1998<steel pressure vessel>, <Supervision Regulation on Safety Technology for Pressure Vessel, Regulation of Safety Supervision for Liquefied Gas Tank Car>.
