China famous brand JAC Brand 5tons Refrigerator Freezer for sale, factory JAC 4*2 LHD sale cold room truck for sale
China famous brand JAC Brand 5tons Refrigerator Freezer for sale, factory JAC 4*2 LHD sale cold room truck for sale
Chengli Famous Thermo King Refrigerator Truck 4x2 Food Meat Transportation Cooling Van Truck Freezer Truck For Sale
Main parameter of hot sale China famous JAC brand cold room truck with THERMO KING refeer as below
|
Item |
Parameter |
|
Production name |
refrigerator truck |
|
vehicle model |
JAC refrigerated truck for frozen meat |
|
Engine |
Engine model: HFC4DA1-2B2 |
|
Engine manufacturer: JAC Automobile Co., LTD |
|
|
Exhaust: 2771ml |
|
|
Power: 88kw |
|
|
Chassis model |
BJ1042L3K4T |
|
Tire |
Tire specification: 7.00-16 |
|
Number of tire:6 |
|
|
Axle |
Number of axles: 2 |
|
Axle-load: 1555/2765 |
|
|
Wheel base(mm): 3360 |
|
|
Traction system |
4*2 |
|
Tank fact cubage(cbm) |
4-5 |
|
GVW(kg) |
4320 |
|
Curb weight(kg) |
2700 |
|
Rated load(kg) |
1490 |
|
Overall dimensions(mm) |
5995×1910×2900 |
|
F / R track base(mm) |
1440/1425 |
|
F/R overhang(mm) |
1105/1530 |
|
Approach / departure angle(°) |
24/15 |
|
Max speed(Km/h) |
98 |
|
Equipment and Function |
Equipment: chassis, the heat preservation box body--standard material is glass fiber reinforced plastic, 8mm polyurethane insulation layer, Standard back open door and refrigeration unit; Optional: polyurethane material, color steel plate, stainless steel, etc, 5mm insulation layer, side open door; Function: transport frozen foods (ice truck), dairy (milk truck) fruits and vegetables (fresh transporter) vaccine and vaccine truck, etc
|
Refrigerator panel description:
1. Drive model:4*2,6*2,6*4,8*4; Chassis Brand : Dongfeng, FAW, Auman, Shacman, Sinotruck, North Benz( Bei Ben), etc.
2. Cab: Flat-head/High-head with one sleeper(optional), comfortable design, rated passengers:3, with air condition; Steering control: Left hand drive /Right hand drive optional;
3. Length of Cargo body: 10-40inch; Capacity of Cargo body:10-70CBM. The material of the cargo body is opptional according of which kinds of goods the truck transport, with perfect heat preservation, Open model: Read double-open or Side-open.
DC refrigerated truck body
TRUCK BOX DIMENSION (L x W x H) (mm): Accroding to your requirement
|
Insulated body panels |
Floor and roof |
FRP+PU+FRP 100mm thickness(customized) |
|
Rear double doors |
FRP+PU+FRP 100mm thickness(customized) |
|
|
Front panels |
FRP+PU+FRP 100mm thickness(customized) |
|
|
Side panels |
FRP+PU+FRP 100mm thickness(customized) |
|
|
Side door panels |
FRP+PU+FRP 100mm thickness(customized) |
|
|
Parts
|
Sub frame |
Steel (mitsubish chassis) |
|
Rear doorframe |
Stainless steel |
|
|
Rear door hardware (locks ,hinges lock bar) |
Stainless steel |
|
|
Side doorframe |
Stainless steel |
|
|
Side door hardware (locks ,hinges lock bar) |
Stainless steel |
|
|
Seal strips |
Standard |
|
|
Fender apron |
Aluminum Standard |
|
|
Wrap angle& empennage |
Standard |
|
|
Stand column |
Aluminum Standard |
|
|
Aluminum profile |
Aluminum Standard |
|
|
Top inside the lamp |
LED |
|
|
Floor panels |
Aluminum decorative pattern(2.0mm) |
|
|
Other parts |
sealant,rivet,drain-pipe,bumping post and so on |
|
|
Standard configuration and installed as a whole when shipped |
If you're interested in our dongfeng 145 cold room truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Refrigeration unit
Technical Data for Refrigerator Freezer in Dubai T110F:
| Model | T110F | T230F |
|
Temperature rating in container |
-18°C~+25°C |
|
| Cooling capacity(W) |
800(-18°C) |
1200(-18°C) |
| Volume of container(m³) |
2~5(-18°C) |
5~9(-18°C) |
| Voltage | DC12/24V | |
| Compressor | SD5H11 | SD5H14 |
| Refrigerant | R404a 1.0~1.1kg | R404a 1.3~1.4kg |
| Dimension of Evaporator |
510*600*138mm |
550*695*165mm |
| Dimension of Condenser |
865*700*185mm |
1020*865*210mm |
Refrigerateor brand for reference:
Thermo king,Kingtec, Carrier,Lambert, Chereau
More pictures of refrigerated trucks manufactured by Chengli Special Automobile Co., Ltd.
More pictures of hot sale jAC brand refrigerated van truck as below
JAC brand cold room truck for sale
JAC brand double cabs refrigerated truck for sale
