40 metric tons buried lpg gas tanker for export, hot sale 100,000L ASME standard underground lpg gas propane tank
40 metric tons buried lpg gas tanker for export, hot sale 100,000L ASME standard underground lpg gas propane tank
As a professional lpg tank manufacturer in China, Chengli Special Automobile Co., Ltd. have the aptitude to design and manufacture A2 type of pressure vessel, C2 type of lpg tank truck, C3 type of LPG tank container. The manufacturing processing of lpg tank is complex and strict. All the lpg gas tanks must do nondestructive examination, air tight test, hydrostatic test and any other inspections.
The lpg storage tank we produce are horizontal lpg tank, vertical lpg tank. It mainly used to store up liquid petrolum gas, propane. We also produce pressure vessel to store liquid ammonia, dimethyl .
If you're interested in our lpg gas pressure vessels, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
The main technical parameters of 100,000L stationary bullet type underground lpg gas storage tanks manufactured by Chengli Special Automobile Co., Ltd.
|
Nozzle table (the place of the nozzle for your reference
|
Main technical characteristics | |||||||||
| Sign | Nominal size | Nominal pressure | Connection standard and form | Connecting forms | Usage &name | Tanker | Item | Data | Item | Data |
| a | DN50 | 25 | HG20592-WN | RF | Pipe for liquid in | Filling medium | LPG(propane) | Tanker mass | 20,840kg | |
| b1 | DN50 | 25 | HG20592-WN | RF | Pipe for liquid out | Volume | 100,000L | Filling mass | 39,900kg | |
| b2 | DN50 | 25 | HG20592-WN | RF | Drain outlet | Designed pressure | 1.77MPa |
Dimension
(diameter*thickness*length)(mm) |
3100*16*13866 | |
| c1-2 | DN50 | 25 | HG20592-WN | RF | Balance valve for air phrase | Cylinder design thickness | 15.58mm | |||
| d | DN100 | 25 | HG20592-WN | RF | Safety valve | Head design thickness | 15.87mm | Filling coefficient | 0.95 | |
| e | M33×2 | - | Whod | Pipe for thermometer | Main material | Q345R | Hydrostatic test pressure | 2.22Mpa | ||
| f | DN150 | 25 | HG20592-WN | RF | Pipe for liquid level gauge | Corrosion allowance | 1mm | Age limit | 15 years | |
| g | M20×1.5 | - | Whod | Pipe for pressure gauge | Heat treatment | Stress relief | Density(kg/m3 ) | 420(50℃) | ||
| h1-2 | DN450 | 25 | HG20592-WN | FM | Manhole |
100cbm LPG gas tanker(propane)
|
Chengli Special Automobile Co. ,Ltd. | |||
| i | DN50 | 25 | HG20592-WN | Empty hole | liquid level gauge | |||||
The lpg storage tank is also called LPG gas tank, lpg tank, lpg storage tank, lpg gas storage tank,bulk lpg storage tanks, etc. The lpg storage tank is belong to pressure vessels.
40 metric tons lpg gas tanker for export, hot sale 100,000L ASME lpg gas propane tank
hot sale clw brand lpg gas storage tank for sale
underground 40 metric tons lpg gas storage tank for sale
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
