LPG gas semitrailer for liquid ammonia for sale, factory direct sale bulk ammonia lpg gas trailer with cheapest price
CLW9404GYQ LPG gas semitrailer for liquid ammonia for sale, hot sale lpg gas ammonia tank trailer
Safety Acessories of lpg tank for sale:
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas tank, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
Pressure Gauge, Safety relief valve , Level Gauge, Cut-off valve, Thermometer,etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of LPG gas semitrailer and LPG gas storage tank, etc. And the LPG gas semitrailer tank volume is from 40000L to 60000L. And the loading medium can be propane, liquid ammonia, propene, dimethyl , isobutane, etc. More information, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995.
| Item | Specification |
| Semi trailer Model | CLW9404GYQ LPG gas semitrailer for liquid ammonia for sale |
| Tank Capacity(L) | 49 |
| Loading Medium | LPG gas liquid ammonia |
| Design Pressure(MPa) | 1.91 |
| Max Allowed Pressure(MPa) | 1.91 |
| Design Temperature(degree Celsius) | 50 |
| Overall Dimension(mm) | 12500*2500*3990 |
| Tank Material | Q370R |
| Gross Vehicle Weight(kg) | 40000 |
| Payload(kg) | 25970 |
| Curb Weight(kg) | 14030 |
| Axle No. | 3 |
| Axle Specification | 13T FUWA axle OR BPW |
| Wheelbase(mm) | 6800+1310+1310 |
| Landing Gear | 28T FUWA or JOST |
| King Pin | 2.5’’,3.5’’is optional |
| Tire Specification | 12.00R22.5 12PR |
| Tire Number | 12 tires |
| Leaf Spring No. | -/7/7/7 |
| Axle Load(kg) | -/24000(parallel installed) |
| Main basic equipments | 1. Tank material: Q370 R ,thickness 13.5mm, two Ellipsoidal head cover, thickness 9mm ,design pressure: 1.91Mpa ,design Temperature: 50°C |
| 2. Equipped with 13ton BPW axle, 28ton JOST outrigger, 90# JOST King pin, | |
| 3.Equipped with two valve boxes, two tool boxes, safety valve, thermometer, pressure gauge, emergency shut-off valve, fire extinguisher, anti-static ground tape, two side loading & unloading ,one independent liquid outlet |
3. Advantages of LPG gas storage tank:
a.) Fixed-point procurement of raw material manufacturer
b.) Strictly inspection for incoming material
c.) Vigorous production process
d.) Nondestructive examination / 100% X-ray testing
e.) Water pressure and air tightness testing
Tank shaped use the advanced welding technology, end socket arc butt welding, and the once-forming of composite steel-plastic technology. Equipped with active and passive safety devices to meet an emergency and can load and unload the material in long distance and completely close condition. Be applied to transport varied oil, feul and chemical material, such as natural gas, liquefied petroleum gas, liquefied ammonia, carbon bisulfide, epoxyethane,gas, butane, dimethylmethane, propylene, etc. Cross section of tank could be oval, round and round-square. heat insulation and heating device is optional.
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
