Euro 3 dongfeng tianjin Cummins 170hp livestock and poultry transportation feed tank truck, farm-oriented feed truck

Euro 3 dongfeng Tianjin 12cbm bulk feed truck

Product name

Bulk feed transportation truck

Overall dimension(L*W*H)

7700×2500×3550(mm)

Tank volume

12m

Compartments

2 compartments with 2 different feeds

Discharging speed

400-500KG/min

Tank dimension

discharging rotation angle

±180 degree

Total mass

12490 (kg)

dischargingmaxangle of elevation:

60 degree

Rated mass

5990 (kg)

horizontal distance of supplying

6.1m

Curb mass

6305 (kg)

Vertical distance of supplying

7.6m

Max speed

85 (km/h)

Remark

1, the tank material adopts high quality carbon steel, equips with high quality electronic auger, 12m discharging all.

2,The feed tank is with 2compartments to load 2 kinds of feeds with separate discharging operation system.

3, Sealed transportation and reducing wastage, saving manpower and bag price, easy operation and maintenance.
5, Low centre of gravity, reliable loading and discharging, good appearance with high quality

CLW5161ZSLD3 bulk feed truck chassis

Chassis model

DFL1120B1

Fuel type

Diesel

Axle nos.

2

Emission standard

Euro 3

Tyre nos.

6

Tyre specification

9.00-20

Engine

Cummins 170hp

Wheelbase

3800

Chassis remark

Tianjin flathead luxurious driver can with sleeper, Cummins 170hp diesel engine, dongfeng 6 speed transmission, 9.00-20 tyre

Average discharging speed(kg/min)

510-560

Rotation angle of auger when discharging

±180 degree

max elevation angle of auger when discharging

70 degree

Delivery distance

Horizontal max range(m)

7.5

Vertical max range(m)

8.2

Residual rate

No more than 0.10
