SINO TRUK Wangpai 22cbm bulk feed pellet transportation vehicle for sale,SINO TRUK 8tons-12tons animal feed truck
SINO TRUK Wangpai 22cbm bulk feed pellet transportation vehicle for sale,SINO TRUK 8tons-12tons animal feed truck
Main parameters of hot sale SINO TRUK wangpai brand 22m3 electronic/hydraulic discharging system farm-oriented feed truck as below
|
SINO TRUK Wangpai 22cbm bulk feed pellet transportation vehicle for sale |
|||
|
Total mass(kg) |
15380 |
Curb mass(kg) |
7685 |
|
Rated mass(kg) |
7500 |
Chassis model |
CDW1160A2C4 |
|
Driver cab person |
3 |
Front/rear suspension(mm) |
1285/2415,1285/2615 |
|
Approach/departure angle (°) |
24/23 |
Max speed(km/h) |
90 |
|
Overall dimension(L*W*H)(mm) |
9000X2450X3700 |
Cargo body dimension |
XX |
|
Axle nos. |
2 |
Axle load(kg) |
5600/9780 |
|
Tyre |
9.00-20,9.00R20 |
Tyre nos. |
6 |
|
Front tread(mm) |
1755 |
Rear tread |
1750 |
|
Wheelbase(mm) |
5300,5100 |
Steel spring |
11/10+8 |
|
Emission standard |
Euro 4 |
Fuel type |
Diesel |
|
Engine model |
Manufacturer |
Displacement |
Power |
|
YC4E160-42 |
Yuchai |
4260 |
118 |
SINO TRUK Wangpai 22cbm feeds pellet truck, adopts Wangpai original cargo truck chassis, 5300mm wheelbase, 2080mm one row and a sleeper driver cab, Yuchai 160hp inter-cooling Euro 3/Euro 4 engine, 6 speed transmission, 10ton rear bridge, 9.00-20 tyre, power steering air-cut brake, etc.
The bulk feed tank volume is 22cbm(and the feed density is from 0.5ton/cbm to 0.65ton/cbm), adopting electronic auger type transferring feeds, putting on 380 Volt three mutually alternate current, then working. Discharging is by electronic motor driven the screw mechanism with high speed, continuous working, highly improving the working productiveness.
The feed tank is usually with 3 compartments, loading and discharging with three different kinds feeds. Simple unit structures. electric cabinet unity is at the rear part of the tank. Easy and flexible to operate and maintenance.
If you're interested in our poultry feed truck, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995
Website: www.trucksinchina.com
main technical parameters of hot sale poultry feed truck as below
hot sale 22m3 feed truck
electronic system discharging feed delivery truck for sale
hot sale SINO TRUK Wangpai farm-oriented feed truck
More information, please feel free to contact with us.
Skype: truck0011
Whatsapp/wechat: +86 13329899995
QQ: 504873236
|
Average discharging speed(kg/min) |
510-560 |
|
|
Rotation angle of auger when discharging |
±180 degree |
|
|
max elevation angle of auger when discharging |
60 degree |
|
|
Delivery distance |
Horizontal max range(m) |
7.2 |
|
Vertical max range(m) |
8.2 |
|
|
Residual rate |
No more than 0.10 |
|
