forland 5,000L milk tank truck for sale, hot sale stainless steel liquid food tank truck
The milk tank truck for sale is also called milk tank truck, milk transport truck, milk tanker truck, milk transport tank truck, truck for milk transportation, milk truck, liquid food transport truck, etc.
The milk tanker we produce is mainly used to transport fresh milk, liquid food, etc. The tank is made of sus304 stainless steel, middle with insulated layer to keep the temperature and the outer is with stainless steel cover. Also, the tank can be devided into several compartment to transport different material.
The inner of the tank is with CIP automatic cleaning device, which can clean the tank after discharge the milk to aviod food pollution.
The pipeline and valves of the milk truck are all food grade, which is high safe.
If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/MOb.: +86 13329899995.
Website: www.trucksinchina.com
Main feature of milk transport tank truck
1.Polished stainless steel, 4mm thick inner and 2mm thick for outer.
2.80-110mm insulated layer, not more than 1°C rise in temperature in 24 hours.
3. Stainless steel 2" milk outlet with a butterly valve.
4. Stainless steel access ladder to the top of the tank.
5. Equipment with automatic with spray dish technology inside the tank and a CIP joint at the back.
6. Stainless steel manhole and dust cover be designed to prevent overflow and leakage from the top.
7. Anti-skid platform on the top of tank body made of chequered aluminum alloy plate with skid resistant surface.
8. Foding Stainless steel hand rail.
Main Parameter of 4*2 FORLAND Milk Tank Truck 3m3:
|
Main Technical Parameter |
|||
|
Product Model |
FORLAND Milk Tank Truck |
Overall Dimension(L*W*H)(mm) |
5320×1800×2300 |
|
Fact Cubage (m3) |
3 |
Curb weight(kg) |
2535 |
|
Payload(kg) |
Approx 2400 |
Wheelbase(mm) |
2600 |
|
Steering type |
LHD or RHD |
Max Speed (km/h) |
90 |
|
Cab capacity |
2 |
Cab type |
Single row, flat proof |
|
Chassis Technical Parameter |
|||
|
Chassis Model: |
BJ1042 |
Chassis Manufacturer: |
Beijing FONTON Motor Co., Ltd |
|
Brake System |
Air brake |
Transmission type: |
Manual with 5 shift |
|
Axle number |
2 |
Traction Type: |
4*2 |
|
Tire size |
7.00-16 |
Number of Tire |
6 with a spare |
|
Engine specification |
|||
|
Engine Model: |
4B1-82C40 |
Engine Brand |
Anhui Quanchai |
|
Emission stand |
Euro 3 |
Displacement(ml) |
2270 |
|
Fuel type: |
Diesel |
Power(kw) |
60/82hp |
|
Warranty |
12 months, from the date of supply |
||
|
Superstructure parameter |
1. 24V Electric system |
||
|
2. Material: inner 4mm Food grade stainless steel, middle 80mm foam insulation layer, outside 2mm ordinary Brushed shape stainless |
|||
|
3. Three unattached small storehouse to fill different kinds of Liquid Foods |
|||
|
4.Equipped with food grade valve and interface, with PIC automatic cleaning device in every storehouse |
|||
More pictures of hot sale forland small 5,000L fresh milk tank truck manufactured by Chengli Special Automobile Co., Ltd. as below.
hot sale stainless steel liquid food tank truck
forland fresh milk truck for sale
forland milk truck with two compartments for sale
