3 axles BPW/FUWA steel suspension/ air suspension 59.4cbm LPG semitrailer for propane for sale, lpg gas tank trailer
3 axles BPW/FUWA steel suspension/ air suspension 59.4cbm LPG semitrailer for propane for sale, lpg gas tank trailer for sale
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide,etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas tank, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng. send email to truck0011@163.com; or tralk to Anita directly by whatsapp/wechat: +86 13329899995.
The main parameters of hot sale 59.4m3 bulk propane gas trailer manufactured by Chengli Special Automobile Co., Ltd. as below.
|
3 axles 59.4cbm LPG semitrailer for propane |
|||
|
Total mass(kg) |
40000 |
Curb mass(kg) |
15050 |
|
Rated mass(kg) |
24950 |
Axle load(kg) |
-/24000( triple axles) |
|
Driver cab person |
|
Bearing mass of semitrailer saddle(kg) |
16000 |
|
Approach/departure angle(°) |
-/17 |
Front/rear suspension(mm) |
-/1590 |
|
Overall dimension(mm) |
13000×2500×4000 |
Cargo body dimension(mm) |
XX |
|
Tyre |
12R22.5 12PR |
Tyre nos. |
12 |
|
Front tread(mm) |
- |
Rear tread(mm) |
1840/1840/1840 |
|
Wheelbase(mm) |
7230+1310+1310 |
Springs |
-/4/4/4,-/7/7/7 |
|
Others |
The tank volume is 59.4cbm. The tanker material adopts Q345R. The propane design pressure is 1.61Mpa, the test pressure is 2.1Mpa, designed temperature is 50 degree, filling volume is 0.42ton/cbm, and corrosion allowance is 1mm. The tanker thickness is 11.5mm, two ellipse end heads (11.5mm thick). The loading medium is LPG gas(Propane), the medium density is 442kg/m3. And the tanker will be with the Flammable and explosive identification.
The standard devices of the 59.4cbm LPG tank semitrailer for propane are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton BPW bridges (FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.
And the LPG trailer chooses to install aluminum alloy sun shield with slow heat transfer and fast heat dissipation.
|
||
|
Function introduction |
“CLW” brand LPG storage tanker semitrailer manufactured by Chengli Special Automobile Co., Ltd. adopts scientific leading treatments, assuring the lowest Shrinkage and highest dimension stability at the low temperature. The advantages of the LPG storage tanker are low-temperature storage, easy transporting, safe and reliable, easy maintain, etc. The LPG storage tankers are suitable for storing LPG, liquid ammonia, carbon disulfide, epoxyethane, gasoline, butane, propane, propene, etc. All the LPG tank trucks and LPG pressure vessels manufactured by Chengli Special Automobile Co., Ltd. are line with the GB150-1998<steel pressure vessel>, <Supervision Regulation on Safety Technology for Pressure Vessel, Regulation of Safety Supervision for Liquefied Gas Tank Car>. |
||
59.4M3 LPG gas semitrailer for propane adopts13ton FUWA triple axles, 12 sets 12.00-20 vacuum tyre, and another spare tyre, JOST 28ton outrigger, JOST traction pin, fire extinguisher bottle, anti-static tape.
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton FUWA bridges, 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.
The LPG tanker semi-trailer is line with the GB150-1998, <<Supervision Regulation On Safety Technology for Pressure Vessel>>, <<Regulation of Safety Supervision for Liquefied Gas Tank Car>>.
We can also manufacture ASME standard lpg gas trailer, lpg gas tank, lpg gas truck, skid lpg gas filling plant, etc. And we can design and produce lpg gas pressure vessels customized.
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas pressure vessels, such as lpg gas trailer, lpg gas delivery truck, lpg gas dispenser vehicle, lpg gas tank, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
More pictures of hot sale 59.4M3 lpg gas trailer as below.
