factory direct sale best price triple axles 48700L DME lpg gas trailer, high quality 27tons DME lpg gas trailer for sale

3 axles 48.7cbm LPG semitrailer for DME

 Total mass(kg)

40000

Curb mass(kg)

 12630

 Rated mass(kg)

27370

 Axle load(kg)

 -/24000( triple axles)

 Driver cab person

 Bearing mass of semitrailer saddle(kg)

 16000

 Approach/departure angle(°)

 -/14

 Front/rear suspension(mm)

 -/1750

 Overall dimension(mm)

11450×2500×3970

 Cargo body dimension(mm)

 XX

Tyre

 12R22.5 12PR

Tyre nos.

 12

 Front tread(mm)

 -

 Rear tread(mm)

 1840/1840/1840

 Wheelbase(mm)

 5500+1310+1310

 Springs

-/4/4/4,

Others

The tank volume is 48.7cbm. The tanker material adopts Q345R. The propane design pressure is 1.15Mpa, designed temperature is 50 degree, filling volume is 0.562ton/cbm. The tanker thickness is 10mm, two ellipse end heads (10mm thick). The loading medium is LPG gas(DME). And the tanker will be with the Flammable and explosive identification.

The standard devices of the 48.7cbm LPG tank semitrailer for DME are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton BPW bridges (FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.

And the LPG trailer chooses to install aluminum alloy sun shield with slow heat transfer and fast heat dissipation.



Function introduction

“CLW” brand LPG storage tanker semitrailer manufactured by Chengli Special Automobile Co., Ltd. adopts scientific leading treatments, assuring the lowest Shrinkage and highest dimension stability at the low temperature.  The advantages of the LPG storage tanker are low-temperature storage, easy transporting, safe and reliable, easy maintain, etc. The LPG storage tankers are suitable for storing LPG, liquid ammonia, carbon disulfide, epoxyethane, gasoline, butane, propane, propene, etc.
All the LPG tank trucks and LPG pressure vessels manufactured by Chengli Special Automobile Co., Ltd. are line with the GB150-1998<steel pressure vessel>, <Supervision Regulation on Safety Technology for Pressure Vessel, Regulation of Safety Supervision for Liquefied Gas Tank Car>.
