ASME standard road transported lpg gas tank trailer for sale, hot sale CLW brand 54m3 bulk propane gas tank trailer
ASME standard road transported lpg gas tank trailer for sale, hot sale CLW brand 54m3 bulk propane gas tank trailer
Specifications of lpg gas pressure vessesl manufactured by Chengli Special Automobile Co., Ltd. as below
1. LPG Semi trailer LPG trailer LPG tank trailer LPG tanker trailer
2. LPG storage tank
3. LPG Three Axle Semi Trailer
4.40 CBM, 45CBM. 50CBM,54cbm 56cbm 60CBM propane Semi Trailer
5. Certification: ISO9001 CCC SGS
LPG trailer brief---
1)Designing pressure: 1.61MPa Designing temperature: -20C-50C
2)The various types LPG tanker is researched and manufactured by stress analysis design and has obvious advantage of large capacity. Light weight and high efficiency.
3)We inspect the quality of product strictly, ensure that A and B type of welding seam pass the examination of level two radiographic test, C and D type of welding seam pass the examination of level one radiographic test.
4)There are domestic or imported safety accessories with high quality, its matching is complete.
5)The anticorrosion coating of LPG tanker adopt the following process, sandblast, spray painting, purging and so on.
More information, please feel free to send email to truck0011@163.com; or talk to Anita directly by whatsapp/wechat: +86 13329899995
The main technical parameters of ASME standard road transported lpg gas tank trailer for sale, hot sale CLW brand 54m3 bulk propane gas tank trailer as below
|
Item |
Unit |
Parameter |
|||
|
Product name |
|
ASME tanker trailer lpg tank trailers 54cbm tank semi trailer propane tank lpg tank semi-trailer |
|||
|
Practical capacity |
M3 |
59.52 |
|||
|
Gross weight |
kg |
40000 |
|||
|
Curb weight |
15000 |
||||
|
rated loading capacity |
25000 |
||||
|
Overall dimension |
mm |
13000*2500*3990 |
|||
|
Axle |
3 |
||||
|
Wheelbase |
7230+1310+1310 |
||||
|
Tread |
Front tread |
- |
|||
|
Rear tread |
1840/1840/1840 |
||||
|
Front/rear suspension |
mm |
-/1745 |
|||
|
Leaf spring |
|
-7/7/7 |
|||
|
Fifth wheel max loading |
kg |
16000 |
|||
|
Tyre specification |
|
12.00-20 |
|||
|
Exclusive configuration |
Tank material |
Q345R |
|||
|
Standard configuration |
13T BPWor FUWAaxle, safety valve,single fluid two valve box.hydraulic legs,traction pin,liquid Indicator,pressure gauge, temperature gauge,emergency cut-off valve,valve box,fire suppression bottle,spark hider cover,anti static grounding tape,protective guard,tyre protective shield. |
||||
|
Other |
Filling Medium:propane:design pressure 2.16Mpa, design temperature 50°C,filling ratio:0.42t/m3, corrosion allowance:1mm:dimension of tank:12837*11.5*2475mm . |
||||
|
Standard configuration |
GB150-1998,Supervision regulation on safety technology for pressure vessel,Supervision regulation on safety technology for Liquefy gas tank truck.
|
||||
More information, please feel free to contact with Ms. Anita.
Whatsapp: +86 13329899995
Skype: truck0011
QQ: 504873236
