factory price 59.52m3 lpg gas propane tanker trailer for sale, hot sale 59520L bulk cooking gas transported tank trailer

59.52cbm 3 axle LPG tanker semi-trailer for propane main parameters

More information, please send email  to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995

59.52cbm 3 axle LPG tanker semi-trailer for propane main parameters

 Total mass(kg)

 40000

 Curb mass(kg)

 15000

 Rated mass(kg)

 25000

 Chassis model

 Driver  cab

The bearing mass of semitrailer saddle (kg)

 16000

 Approach/departure angle(°)

 -/20

 Front/rear suspension

 -/1540

 Overall dimension(mm)

 13000X2500X3990

 Cargo body dimension(mm)

 XX

Axles

 3

Axle load

 -/24000(three axles)

Wheelbase(mm)

7230+1310+1310

Springs

-/7/7/7

Others

The tank volume is 59.52cbm. The tanker material adopts Q370R. The propane design pressure is 1.61Mpa, the test pressure is 2.1Mpa, designed temperature is 50 degree, filling volume is 0.42ton/cbm, and corrosion allowance is 1mm. The tanker thickness is 11.5mm, two ellipse heads (12mm thick). The loading medium is LPG (Propane), the medium density is 442kg/m3. And the tanker will be with the Flammable and explosive identification.

The standard devices of the 59.52cbm LPG tank semitrailer for propane are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton BPW bridges (FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.


Function introduction

“CLW” brand LPG storage tanker semitrailer manufactured by Chengli Special Automobile Co., Ltd. adopts scientific leading treatments, assuring the lowest Shrinkage and highest dimension stability at the low temperature.  The advantages of the LPG storage tanker are low-temperature storage, easy transporting, safe and reliable, easy maintain, etc. The LPG storage tankers are suitable for storing LPG, liquid ammonia, carbon disulfide, epoxyethane, gasoline, butane, propane, propene, etc.
All the LPG tank trucks and LPG pressure vessels manufactured by Chengli Special Automobile Co., Ltd. are line with the GB150-1998<steel pressure vessel>, <Supervision Regulation on Safety Technology for Pressure Vessel, Regulation of Safety Supervision for Liquefied Gas Tank Car>.

More information of the LPG tanker semi-trailer, please contact Anita Deng.
