factory price 60 CBM Tri axles LPG gas tank semi trailer for sale, high quality lpg gas propane tank trailer for sale
factory price 60 CBM Tri axles LPG gas tank semi trailer for sale, high quality lpg gas propane tank trailer for sale
1)Designing pressure:1.77Mpa Designing temperature:-20C-50C
2)The various types LPG tanker is researched and manufactured by stress analysis design and has obvious advantage of large capacity.light weight and high efficiency.
3)We inspect the quality of product strictly,ensure that A and B type of welding seam pass the examination of level two radiographic test,C and D type of welding seam pass the examination of level one radiographic test.
4)There are domestic or imported safety accessories with high quality ,its matching is complete.
5)The anticorrosion coating of LPG tanker adopt the following process, sandblast, spray painting ,purging and so on.
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
More pictures of LPG Semi-trailer manufactured by Chengli Special Automobile Co., Ltd. as below
hot sale road transported lpg gas tank
hot sale lpg gas trailer for sale
CLW brand lpg gas pressure vessels passed US ASME standard- US ASME certificate
LPG Semi-trailer specification as below
|
Item |
Unit |
Parameter |
||
|
Product name |
|
3 axle semi-trailer |
||
|
Practical capacity |
M3 |
60 |
||
|
Gross weight |
kg |
40000 |
||
|
Curb weight |
15430 |
|||
|
rated loading capacity |
24570 |
|||
|
Overall dimension |
mm |
11360*2490*3980 |
||
|
Axle |
3 |
|||
|
Wheelbase |
5100+1320+1320 |
|||
|
Tread |
Front tread |
- |
||
|
Rear tread |
1840/1840/1840 |
|||
|
Front/rear suspension |
mm |
-/1745 |
||
|
Leaf spring |
|
-7/7/7 |
||
|
Fifth wheel max loading |
kg |
16000 |
||
|
Tyre specification |
|
12.00-20 |
||
|
Exclusive configuration |
Tank material |
Q345R |
||
|
Standard configuration |
12T BPW axle, safety valve,single fluid two valve box.hydraulic legs,traction pin,liquid Indicator,pressure gauge,temperature gauge,emergency cut-off valve,valve box,fire suppression bottle,spark hider cover,anti static grounding tape,protective guard,tyre protective shield. |
|||
|
Other |
Filling Medium:liquid ammonia:design pressure 1.61Mpa,design temperature 50°C,filling ratio:0.42t/m3,corrosion allowance:1mm:dimension of tank:2470*12*12840 |
|||
|
Standard configuration |
GB150-1998<Steel pressure vessels>,Supervision regulation on safety technology for pressure vessel,Supervision regulation on safety technology for Liquefy gas tank truck.
|
|||
