best price ASME standard lpg gas storage tank trailer for sale, China best price road transported propane gas tank

best price ASME standard lpg gas storage tank trailer for sale, factory sale ASME standard lpg gas trailer for sale

Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas pressure vessels, such as lpg gas trailer, lpg gas delivery truck, lpg gas dispenser vehicle, lpg gas tank, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.

Send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995.


Product Description of CLW brand lpg gas pressure vessels as below

OUR LPG trailer is ASME standard .

Our LPG trailer passed 100% X-raying test

Our LPG trailer produced according with client request .

Our LPG trailer use USA Q370R material .

tyre retainer 2 pcs
sun shade cover 1 pcs
liquid level gauge Floating ball on side 1 pcs
single type tyre baffle plate 6 pcs
spare tire rack 2 pcs
spare tyre 2 pcs
FUWA axles 3 pcs
1.641Mpa working pressure 1.61Mpa
Q370R material Q370R
11.5mm tanker thickness 11.5mm
tanker head thickness 11.5mm
tanker curb weight 15000kg
trailer size 13000x2500x3990mm
rear type man hole 1 pcs

More pictures of hot sale ASME standard lpg gas trailer as below.

Dimensions :
Tare Weight : 11500KGS
Pay Load: 25000KGS
Overall Length :11400mm
Overall Width: 2480mm

Photo of LPG tank semitrailer for reference. Final products can be made according to exact requirements

Tank :

Transporting Media Liquid Ammonia, Liquid SO2, LPG, Butane

Shape Round Shape

Total Volume(m3): 55CBM
Tanker Body Steel Sheet: Q235A/11.5mm
End plate : Q235A11.5mm, by punching

Parts for Tank

Manhole cover : 3 sets of 500mm/Q235 manhole fixed on top of Tank, with breather valve
Unloading valve : 2-3 sets of DN80 fixed at button of Tank
Pipeline at button of tank: 4”seamless steel tube/Q235
Labeling system Oil Type Indication

Anti-static electricity system pulling, wire carrier, sheet copper (6 sheet-standard layout)

Other Parts :
Ladder: 1 unit at front of Tank
Guard on top of Tank Zinc galvanized –guard-net
Oil hose box Circular single hole tube, 1 unit on each side
Oil hose : 2 unit, 3” x 6m size in black rubber
Side guard cross bar-structure
Rear button guard Fixed type
Work tank deck Box type
Fire extinguisher box : 2 unit at the back of each side
Mud guard Steel structure in trapezoid form
Lights and wire 24V, 7 coils with lights for parking, reverse, instruction, head lamp and end lamp
Main Beams Heavy duty and extra durability designed; Opting for high tensile steel Q345B,welded by automatic Submerged-Arc processes

Axle : 3 axle

BPW : brand
Landing Gear : JOST Two-speed, manual operating, heavy duty landing gear
King Pin: JOST 2”standard bolt-in king pin
Suspension: German design mechanical suspension

Pneumatic Braking System : WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks

Wheel rim: 8.25R22.5 wheel rim
Tire: 11R22.5 tubeless tire with one spare tire
Painting : Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final painting.

Main parametersProduct nameLpg gas trailer for propene
Product modelCLW9402GYQB propene trailer for saleTotal mass(Kg)40000Tank volume(m3)58.35Rated mass(Kg)25090Overall dimension(mm)13000×2500×3990Curb mass(Kg)14910Cargo body dimension(mm)××Approach/departure angle(°)-/19Front/rear suspension (mm)-/1400Axle nos.3Wheelbase(mm)7350+1320+1320Axle load(Kg)-/24000(triple axles)Max speed(Km/h) RemarkThe transporting medium: propene, and the density: 0.43tons/cbm.
The lpg gas tank volume: 58.35 cubic meters.
Tank overall dimension(Length*diameter): 12819*2472(mm),Chassis main parametersOverall dimension (mm)13000×2500×3990Tyre nos.12Approach/departure angle(°)-/19Tyre specification11.00R20 12PR,12R22.5 12PRSteel spring-/4/4/4,-/7/7/7Front tread(mm) Fuel type Rear tread(mm)1840/1840/1840
