50000L mobile skid mounted lpg gas fiiling stations, 50m3 skid propane cooking gas plant for kitchen gas cylinder bottle
50000L mobile skid mounted lpg gas fiiling stations, 50m3 skid propane cooking gas plant for kitchen gas cylinder bottles for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels, such as bulk lpg tank, lpg gas trailer, lpg gas truck, skid lpg gas filling plant, lpg gas bobtail vehicle, lpg gas dispensing truck, etc. And recently, our company lpg gas pressure vessesl products have passed ASME. That is to say, our lpg pressure vessels can be exported to USA, Europe, etc.
> LPG storage tank with capacity of 5cbm up to 120cbm
> Color : as per customer request
> Dispenser:one gun or two gun dispenser available
> LPG Filling pump with motor
> LPG discharging pump with motor
> LPG hose assembly and quick connector
> Safety Valve+Liquid Level Indication + Pressure Gauge + Thermometer etc
> Other valves and necessary accessories for the operation of lpg filling station
Following is the main technical parameters of 50m3 LPG tank, 50m3 lpg storage tank, 50m3 lpg transport tank ,50000L lpg gas fiiling stations is just for your reference, we aslo do customized products. special requirements, just call me directly Ms. Anita Deng. Please send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
we supply 5-120m3 lpg tank, lpg storage tank, lpg transport tank, lpg tanker trailers, propane transport trailers for sale, propane tanker trailers for sale, 50m3 lpg skid filling station, 50m3 lpg filling skid station, gas filling station, lpg skid-mounted filling station. Top safety 50cbm LPG gas filling cylinder cooking gas station
|
Item |
Unit |
Main parameters |
|
Product name |
|
LPG gas storage tank(50000L) |
|
Product model |
|
CLG2400-50 |
|
Loading medium |
|
LPG gas (propane) |
|
Overall dimension(L*W*H) |
mm |
11508*2428*3018 |
|
Tank dimension(inner diameter*thickness*length) |
mm |
DN2400*14*11508 |
|
Tank volume |
m3 |
50 |
|
Tank thickness |
mm |
14 |
|
End heads thickness |
mm |
14 |
|
Curb mass |
kg |
11140 |
|
Rated mass |
Kg |
19950 |
|
Designed pressure |
Mpa |
1.77 |
|
Working pressure |
Mpa |
≤1.6 |
|
Working temperature |
℃ |
≤50 |
|
Hydraulic test pressure |
Mpa |
2.22 |
|
Air tight test pressure |
Mpa |
1.77 |
|
Tank and main Material pressure components |
Q345R,16Mnlll |
|
|
Standard |
<<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>>
|
|
|
Chosen assembly |
Safety valve, magic level gauge, pressure gauge, temperature gauge, cut-off valve, etc.
|
|
|
Main parts of LPG Tank |
||
|
Item |
Specification |
Quantity |
|
Discharge Pipe |
DN50 |
1 |
|
Inflow Pipe |
DN50 |
1 |
|
Outlet |
DN50 |
1 |
|
Gas phase balance pipes |
DN50 |
2 |
|
Manhole |
DN450 |
1 |
|
Drain Hole |
DN50 |
1 |
|
Electronic LPG Filling Machine |
Can fill 0.5kg to 150kg gas cylinder with receipt printing |
1 |
|
Main accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. Skid Parts List will be show in separated page below. |
||
The spare parts for the LPG Skid-station
|
|
Model Number |
Quantity |
|
Tank |
50CBM |
|
|
Cut-off Valve |
DN50 |
6 Pieces |
|
Cut-off Valve |
DN25 |
2 Pieces |
|
Cut-off Valve |
DN80 |
1 Pieces |
|
Needle Valve |
J24W, M20×1.5 |
1 Pieces |
|
Safety Valve |
DN80 |
1 Pieces |
|
Magnetic reversible level gauge |
UZFAL-2.5RF2640-0.50 |
1 Pieces |
|
Pressure gauge |
M20×1.5 1.5Level 0～4MPA |
1 Pieces |
|
Thermometer |
M33×2 2.5Level |
1 Pieces |
|
Accessory |
Quantity |
|
Cut-off Valve |
9Pieces |
|
Compressor |
1.5MPa |
|
Shock-absorbing Tube |
1 Set |
|
Filling pump machine |
2 Pieces |
|
Discharge Pipe |
5 Miters/set, 2sets |
|
Anti static electric motor |
1 Piece |
|
Bottom Base |
1 Unit |
|
Freight |
To Shanghai Port |
More pictures of hot sale 50,000L skid mounted lpg gas filling plant as below.
More information, please feel free to contact with Ms. Anita deng.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
