Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessel, such as lpg gas tank, lpg gas trailer, skid lpg gas mounted filling station, lpg gas truck, lpg gas dispenser truck, etc.
And the hot sale lpg gas pressure is skid system lpg gas filling station.
Lpg gas skid station, is also called skid system lpg station, propane lpg skid-mounted filling station, lpg mounted skid refilling station, mobile lpg filling station, lpg skid station with dispenser and weight scale, lpg gas cylinder filling station, etc.
This kind of integrative skid lpg gas filling station finishing discharging and filling by the pressure inside the tanker, and the working principles similar to the big size lpg gas filling station at home. The layouts of pipelines, such as inlet, outlet and gas phrase, etc. are reasonable, Practical, and artistic, etc.
And the client said this kind of mobile skid mounted LPG gas propane filling station is much more welcome all over the world.
We Chengli Special Automobile Co., Ltd. can offer complete LPG Station skid with dual option of Auto vehicle filling and domestic cylinder filling, this station can be on wheels for remote filling or fixed type at site. More information, please feel free to contact with Ms. Anita Deng.
We Chengli Special Automobile Co., Ltd. can offer complete LPG Station skid with dual option of Auto vehicle filling and domestic cylinder filling, this station can be on wheels for remote filling or fixed type at site. More information, please feel free to contact with Ms. Anita Deng. Please send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
Lpg gas skid station, is also called skid system lpg station, propane lpg skid-mounted filling station, lpg mounted skid refilling station, mobile lpg filling station, lpg skid station with dispenser and weight scale, lpg gas cylinder filling station, etc.
Main parameters of hot sale 12m3 skid lpg gas plant as below
| 12 CBM LPG SKID STATION DIMENSIONS | |||
| Volume of Tank | 12 CBM | ||
| Filling Weight | 4488 kg | ||
| Tank Weight | 3360 kg | ||
| Thickness of Shell (mm) | 10 mm | ||
| Thickness of Endplate (mm) | 12 mm | ||
| Tank Diameter (mm) | 1800 mm | ||
| External Dimensions (mm) (length x width x height) | 5034x 1820 x 2410 mm | ||
| Material of Tank and Main Pressure Parts | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( Propane) | ||
| Design Pressure | 1.77 MPa | ||
| Corrosion Allowance | 1 mm | ||
| Medium Density | 420 kg/ cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification | Quantity | |
| Discharge Pipe | DN50 | 1 | |
| Inflow Pipe | DN50 | 1 | |
| Outlet | DN50 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Manhole | DN450 | 1 | |
| Drain Hole | DN50 | 1 | |
| Electronic LPG Filling Machine |
Can fill 0.5kg to 150kg gas cylinder with receipt printing |
1 | |
|
Main accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. Skid Parts List will be show in separated page below. |
|||
The spare parts for the LPG Skid-station
| Model Number | Quantity | |
| Tank | 10CBM | |
| Cut-off Valve | DN50 | 6 Pieces |
| Cut-off Valve | DN25 | 2 Pieces |
| Cut-off Valve | DN50 | 1 Pieces |
| Needle Valve | J24W, M20×1.5 | 1 Pieces |
| Safety Valve | DN50 | 1 Pieces |
| Magnetic reversible level gauge | UZFAL-2.5RF2640-0.50 | 1 Pieces |
| Pressure gauge | M20×1.5 1.5Level 0～4MPA | 1 Pieces |
| Thermometer | M33×2 2.5Level | 1 Pieces |
| Accessory | Quantity |
| Cut-off Valve | 9Pieces |
| Shock-absorbing Tube | 1 Set |
| Filling pump machine | 2 Pieces |
| Discharge Pipe | 5 Miters/set, 2sets |
| Anti static electric motor | 1 Piece |
| Bottom Base | 1 Unit |
More pictures of hot sale 12m3 skid mounted lpg gas filling plant as below.
