80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
80,000L mobile mounted skid lpg gas refilling plant for sale, 80m3 LPG gas filling cylinder cooking gas station for sale
The integrative skid lpg gas filling station finishing discharging and filling by the pressure inside the tanker, and the working principles similar to the big size lpg gas filling station at home. The layouts of pipelines, such as inlet, outlet and gas phrase, etc. are reasonable, Practical, and artistic, etc.
The skid mobile lpg gas propane station is mainly included bulk lpg gas tank, lpg gas pump, cut-off valve, motor, lpg gas disperser machine, filling scale, safety valve, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels, such as bulk lpg tank, lpg gas trailer, lpg gas truck, skid lpg gas filling plant, lpg gas bobtail vehicle, lpg gas dispensing truck, etc. And recently, our company lpg gas pressure vessesl products have passed ASME. That is to say, our lpg pressure vessels can be exported to USA, Europe, etc.
> LPG storage tank with capacity of 5cbm up to 120cbm
> Color : as per customer request
> Dispenser:one gun or two gun dispenser available
> LPG Filling pump with motor
> LPG discharging pump with motor
> LPG hose assembly and quick connector
> Safety Valve+Liquid Level Indication + Pressure Gauge + Thermometer etc
> Other valves and necessary accessories for the operation of lpg filling station.
If you're interested in our skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wecgat/Mob.: +86 13329899995.
Main parameters of hot sale 80,000L mobile skid lpg gas refilling station manufactured by Chengli Special Automobile Co., Ltd. as below
| Item | Unit | Main parameters |
| Product name | LPG gas storage tank(80000L) | |
| Product model | CLG3100-80 | |
| Loading medium | LPG gas (propane) | |
| Overall dimension(L*W*H) | mm | 11166*3132*3722 |
| Tank dimension(inner diameter*thickness*length) | mm | DN3100*16*11166 |
| Tank volume | m3 | 80 |
| Tank thickness | mm | 16 |
| End heads thickness | mm | 18 |
| Curb mass | kg | 17000 |
| Rated mass | Kg | 31920 |
| Designed pressure | Mpa | 1.77 |
| Working pressure | Mpa | ≤1.6 |
| Working temperature | ℃ | ≤50 |
| Hydraulic test pressure | Mpa | 2.22 |
| Air tight test pressure | Mpa | 1.77 |
| Tank and main Material pressure components | Q345R,16Mnlll | |
| Standard |
<<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>>
|
|
| Chosen assembly |
Safety valve, magic level gauge, pressure gauge, temperature gauge, cut-off valve, etc.
|
|
| Main parts of LPG Tank | ||
| Item | Specification | Quantity |
| Discharge Pipe | DN50 | 1 |
| Inflow Pipe | DN50 | 1 |
| Outlet | DN50 | 1 |
| Gas phase balance pipes | DN50 | 2 |
| Manhole | DN450 | 1 |
| Drain Hole | DN50 | 1 |
| Electronic LPG Filling Machine |
Can fill 0.5kg to 150kg gas cylinder with receipt printing |
1 |
|
Main accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. Skid Parts List will be show in separated page below. |
||
The spare parts for the LPG Skid-station
| Model Number | Quantity | |
| Tank | 65CBM | |
| Cut-off Valve | DN50 | 6 Pieces |
| Cut-off Valve | DN25 | 2 Pieces |
| Cut-off Valve | DN80 | 1 Pieces |
| Needle Valve | J24W, M20×1.5 | 1 Pieces |
| Safety Valve | DN80 | 1 Pieces |
| Magnetic reversible level gauge | UZFAL-2.5RF2640-0.50 | 1 Pieces |
| Pressure gauge | M20×1.5 1.5Level 0～4MPA | 1 Pieces |
| Thermometer | M33×2 2.5Level | 1 Pieces |
| Accessory | Quantity |
| Cut-off Valve | 9Pieces |
| Shock-absorbing Tube | 1 Set |
| Filling pump machine | 2 Pieces |
| Discharge Pipe | 5 Miters/set, 2sets |
| Anti static electric motor | 1 Piece |
| Bottom Base | 1 Unit |
| Compressor | 1.5MPa( choose to install, used to fill lpg gas truck) |
| Freight | To Shanghai Port |
More pictures of hot sale 80,000L skid lpg gas refilling plant manufactured by Chengli Special Automobile Co., Ltd.
best price skid lpg gas refilling plant for sale
best price skid lpg gas plant for African Market
