20m3 mobile skid lpg gas filling station for ammonia for sale, hot sale CLW brand 20,000L skid lpg gas refilling plant
20m3 mobile skid lpg gas filling station for ammonia for sale, hot sale high quality and competitive price 20,000L ammonia mobile skid lpg gas filling plant
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years’ development, Chengli can manufacture and sell surface/underground lpg gas storage tanks, lpg gas tank semitrailer, lpg gas truck, lpg gas bobtail vehicle, skid lpg gas refilling station, etc.And last year, our CLW brand lpg gas pressure vessels have passed USA ASME standard. That is to say, our CLW brand lpg gas storage tanks can be esxported to USA, European countries.
Welcome more and more clients all over the world to visit our CLW Group and purchase our CLW brand high quality and best price lpg gas pressure vessels.
If you're interested in our skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
The main technical parameters of hot sale 20m3 mobile skid lpg gas station for ammonia as below
| 20 CBM LPG TANK(AMMONIA) DIMENSIONS | |||
| Volume of Tank | 20,000L | ||
| Filling capacity | 9880kgs | ||
| Tank Weight | 6400kgs | ||
| Thickness of Shell (mm) | 16mm | ||
| Thickness of Endplate (mm) | 16mm | ||
| Tank Diameter (mm) | 2100 mm | ||
| Tank Dimensions (mm) (length x width x height) | 6162*2132*2710 mm | ||
| External Dimensions (mm) (length x width x height) | To be designed to be loaded in a 40’OT container | ||
| Material of Tank | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( ammonia) | ||
| Design Pressure | 2.16 MPa | ||
| Corrosion Allowance | 2 mm | ||
| Medium Density | 520 kg/ cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification/ mm | Quantity | |
| Discharge Pipe | DN50 | 1 | |
| Inflow Pipe | DN50 | 1 | |
| Outlet | DN50 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Manhole | DN450 | 1 | |
| Drain Hole | DN50 | 1 | |
| Other accessories:Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. | |||
| LPG Skid Part list | ||||
| Item | Model Number | Quantity | ||
| LPG Tanker | 20,000L | 1 piece | ||
| Pump | 2" inlet & 2" outlet | 1 Piece | ||
| Explosive-proof Motor | 380V with 220V adapter | 1 Piece | ||
| Electronic Weighting Scale with filling nozzle | Can fill 0.5kg to 150kg LPG cylinder | 1 piece | ||
| Pipes | / | 1 Set | ||
| Cut-off Valve | J41N-40 DN50 | 25 Pieces | ||
| J41N-40 DN15 | 10 Pieces | |||
| Safety Valve | A42F-25 DN50 | 1 Piece | ||
| Pipe Safety Valve | A21F-25 DN15 | 1 Piece | ||
| Level Gauge | Float ball type | 1 Unit | ||
| Discharging pipe | L=4M DN50/DN25 | 1 Piece | ||
| Shock-absorbing Tube | L=500mm DN50 | 2 Pieces | ||
| Flange | 2.5MPaDN15 | 20 Pieces | ||
| LPG Pump & Motor Specification | ||||
| Pump Brand | Chinese brand | |||
| Model | YQB15-5 | |||
| Medium | Liquid petroleum gas | |||
| Working pressure differential | ≤0.5Mpa | |||
| Flow Speed | 15.5M3/H | |||
| Applied Power | 5.5kw | |||
| Inlet & Outlet Flange | 2”NPT / 2" NPT | |||
| Motor | Chinese brand | |||
| Specification | 7.5HP(5.5KW), Explosive Proof, Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
|||
| LPG Cylinder electronic Filling Machines Specification | ||||
| Brand | Kaiyuan | |||
| Model | BCS-150 | |||
| Electricity Voltage | AC220V | |||
| Power | 40W | |||
| Maximum Weighing | 150kg | |||
| Measurement Precision | ±0.5% | |||
| Rated Working Pressure | 1.6Mpa | |||
| Working Temperature | -40℃~+40℃ | |||
| Anti-explosion Rate | Exhibit II BT4 | |||
More pictures of the 20m3 ammonia skid filling plant manufactured by Chengli Special Automobile Co., Ltd. as below.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. Our CLW lpg gas pressure vessels(lpg gas storage tank, lpg gas trailer, lpg gas truck, lpg gas dispensing truck, skid lpg gas filling plant) have been exported to so many countries all over the world. And to meet the needs of the international market, Chengli Special Automoile Co., Ltd. lpg gas pressure vessel factory design and manufacture lpg gas dispensing truck and skid lpg gas filling plant. And last year, we design and produce the first skid lpg gas filling plant for Nigerian client with 40,000L. The client was satisified with the skid lpg gas tank for refilling gas cylinders. This year, we have received so many orders of mobile skid lpg gas filling plants.
