dongfeng RHD Truck Mounted Aerial Working Platform High Altitude Working Truck, dongfeng 18m-22m hydraulic bucket truck
New design dongfeng RHD Truck Mounted Aerial Working Platform High Altitude Working Truck for sale, dongfeng 18m-22m hydraulic bucket truck for sale
Dongfeng aerial working platform with water tank is with the functions of aerial platform and water truck. The working lifting height of the aerial platform is about 16m, water tank volume of 5,000L. The multipurpose truck is with functions of front washing, side spraying, rear sprinkling, water cannon at the rear working platform with 360 degree rotation. The truck equips with China leading large power self-sucking and sield-discharging water pump, safety filter, fire fighting coumpling, and self-charging valve, etc.
If you're interested in our aerial working platform truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
main parameters of hot sale dongfeng RHD 18m-22m truck mounted aerial working paltform high altitude operation truck manufactured by Chengli Special Automobile Co., Ltd. as below
| Description | New design Truck Mounted Aerial Working Platform High Altitude Working Truck RHD for sale | ||
| Drive Model | 4X2 RHD, LHD is selective | ||
| Chassis | EQ1141 | ||
| Vehicle Main Dimensions | Dimensions(L x W x H)mm | 8495×2450×3310 | |
| Wheel base (mm) | 4500 | ||
| Overhang (front/rear) (mm) | 1580/2410 | ||
| Wheel track (front/rear) (mm) | 1940/1860 | ||
| Approach/Departure angle(°) | 34/20 | ||
| Weight in KGS | GVW. | 11750 | |
| Curb Weight | 12180 | ||
| Max. driving speed(km/h) | 88 | ||
| Engine | Model | B170/190 | |
| Type | 4-stroke direct injection , 6 -cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 170/190 | ||
| Emission standard | Euro III | ||
| Gearbox | 5 forwards & 1 reverse | ||
| Clutch | Reinforced diaphragm clutch | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Fuel tank (L) | 200L | ||
| Tire | 10.00R20, 6pieces+1 spare tire | ||
| Brakes | Service brake: dual circuit compressed air brake | ||
| cab: | 3 | ||
| UPPER | |||
| Standard Equipment |
1.Equipped with working bucket, hook, 4 H-type hydraulic outriggers, 2.Equipped with three folded arms, 360 slewing, hydraulic control, on the truck/under the truck operating |
||
|
Technical parameters |
1.Max operation height: 18-22m 2.Max operation radius: 6m 3.Max working platform height 12.5m, 4.Working platform rating loading=300kg, 5.Working platform rating allowable passengers=2 6.Working platform dimension:1100*570*1000mm, 7.Degree of the overturn:360°turning(left or right) 8 Standing Legs: H model , 4pcs, controlled by hydraulic system |
||
More pictures of hot sale dongfeng 153 RHD 190HP 18-22m hydraulic aeiral working platform truck manufactured by Chengli Special Automobile Co., Ltd. as below.
hot sale dongfeng 153 190hp diesel 20m high altitude operation truck
CLW Brand best price dongfeng RHD 20M hydraulic bucket truck for sale
factory direct sale dongfeng RHD aerial working platform truck
Dongfeng aerial working platform with water tank is with the functions of aerial platform and water truck. The working lifting height of the aerial platform is about 16m, water tank volume of 5,000L. The multipurpose truck is with functions of front washing, side spraying, rear sprinkling, water cannon at the rear working platform with 360 degree rotation. The truck equips with China leading large power self-sucking and sield-discharging water pump, safety filter, fire fighting coumpling, and self-charging valve, etc.
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
