Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented feed delivy truck
Foton brand LHD 4*2 livestock and poultry feed truck for sale, factory direct sale FOTON farm-oriented animal feed delivery truck
bulk feed tank is installed on the truck chassis; there is one mouth for loading at the tank top. And the helical delivering discharging pipe (also called discharging auger) on the tank top can rotate and upraise freely with the upraise angle of 60 degree. When transporting, the helical pipe lay on the tank top; when discharging, upraise. Connected the discharging feed outlet with the top inlet of feed storage tank controlled by the operation device at the driver cab or the tank rear part.
With the development of the livestock husbandry, the bulk feeds trucks become more and more important. Some small feedstuff factory actually don’t need large tonnage feed pellet truck. For this, Chengli Special Automobile Co., Ltd. designed and produced new small bulk feed transportation trucks for the small feeds factories, that is dongfeng 4ton bulk feed pellet truck-dongfeng furuika bulk grain carrier. This model of powder feed transportation tank truck is with the volume of 8cbm, adopts dongfeng furuika original chassis, high quality and competitive price, easy operation and maintenance, etc.
If you're interested in our poultry feed truck, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Main parameters of hot sale forland LHD 12tons livestock and poultry feed truck as below
|
Foton brand LHD 4*2 livestock and poultry feed truck for sale Main parameters |
|||
| Product name | Foton brand chick feed transported truck for sale | Overall dimension(mm): | 8450x2336x3600 |
| Truck chassis model | BJ1129VFPEG-FA | Cargo body dimension(mm): | |
| Total mass(kg) | 11375 | Approach/departure angle(° ) | 23°/10° |
| Rated mass(kg) | 4990 | Front/rear suspension(mm): | 1195/2555 |
| Curb mass(kg) | 6190 | Max speed(km/h): | 99 |
| Axle load(kgs) | 3980/7395 | ||
| Truck chassis main parameters | |||
| Truck chassis mode; | BJ1129VFPEG-FA | Fuel type | Diesel |
| Axle load | 2 | Front tread(mm): | 1710,1830 |
| Wheelbase(mm): | 4700 | Rear tread(mm): | 1680,1800 |
| Tire nos. | 6 | Tire specification | 8.25-20 16PR,8.25R20 16PR,9.00-20 14PR,9.00R20 14PR |
| Engine parameters | ||||
| Engine model | Manufacturer | Displacement(ml) | Power (kw) | |
| ISF3.8s4168 ISF3.8s4R168 | Cummins | 3760 3760 | 125 125 | |
| Emission standard | Euro 4 | Fuel type | Diesel | |
| Feed tank volume | 20cbm | Discharging speed | 500-600 kg/min |
| Full discharging time | 18mins | Discharging max elevation | 70 degree |
| Horizontal delivering range | 6.5m | Rotation angle of discharging | 180 degree |
| Vertical delivering range | 8.3m | Compartments | 3 compartments loading 3 different kinds of feeds |
| Discharging way | Hydraulic auger system discharging, 380Volts electronis auger discharging is selective. | ||
Remark: 1, for the density of the feeds is various, so the loading tonnage is also various. The tank volume is 20cbm.
when the feeds density is 0.55ton/cbm, 0.6ton/cbm, 0.7ton/cbm, the loading mass is 11ton, 12ton, 14ton.
2, the bulk feeds truck adopts the special bulk feeds truck chassis, widely for long distance transportation, large size feedstuff factories, etc.
More pictures of hot sale FOTON brand chick feed pellet truck as below.
animal feed delivery truck for sale
FOTON brand livestock and poultry feed delivery truck for sale
hydraulic animal feed truck for sale
