2021s best seller 10tons lpg gas storage tank with filling machine for gas cylinders, 10T skid lpg gas filling plant
2021s best seller 10tons lpg gas storage tank with filling machine for gas cylinders, 10metric tons mobile skid-mounted lpg gas filling plant for sale
The finished full set of skid-mounted lpg gas plant is well-appinted, installed with lpg gas vane pump, motor, electronic scale etc. The clients can use it to fill gas cylinders directly. And at the same time, we can design and manufacture ASME standard ones. The mobile skid-mounted lpg gas plant is ask for higher installing quality. more and more clients choose our CLW brand company, that is to say our CLW brand lpg gas pressure vessels gain acceptance at home and overseas.
If you're interested in our skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
main technical parameters of hot sale 25,000L skid lpg gas refilling stations manufactured by Chengli Special Automobile Co., Ltd. as below.
| 25,000L LPG TANK DIMENSIONS | |||
| Volume of Tank | 25,000L | ||
| Filling capacity | 9975kgs | ||
| Tank Weight | 6020kgs | ||
| Thickness of Shell (mm) | 12mm | ||
| Thickness of Endplate (mm) | 14mm | ||
| Tank Diameter (mm) | 2200 mm | ||
| Tank Dimensions (mm) (length x width x height) | 7008*2224*2814mm | ||
| External Dimensions (mm) (length x width x height) | To be designed to be loaded in a 40’container | ||
| Material of Tank | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( Propane) | ||
| Design Pressure | 1.77 MPa | ||
| Corrosion Allowance | 1 mm | ||
| Medium Density | 420-590 kg/ cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification/ mm | Quantity | |
| Discharge Pipe | DN50 | 1 | |
| Inflow Pipe | DN50 | 1 | |
| Outlet | DN50 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Manhole | DN450 | 1 | |
| Drain Hole | DN50 | 1 | |
| Other accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. | |||
| LPG Skid Parts list | |||
| Item | Model Number | Quantity | |
| LPG Tanker | 25,000L | 1 piece | |
| Pump | 2" inlet & 2" outlet | 1 Piece | |
| Explosive-proof Motor | 380V with 220V adapter | 1 Piece | |
| Electronic Weighting Scales with filling nozzles | Can fill 1kg to 150kg LPG cylinders | 1 pieces | |
| Pipes | / | 1 Sets | |
| Cut-off Valve | J41N-40 DN50 | 25 Pieces | |
| J41N-40 DN15 | 10 Pieces | ||
| Safety Valve | A42F-25 DN50 | 1 Piece | |
| Pipe Safety Valve | A21F-25 DN15 | 1 Piece | |
| Level Gauge | Float ball type | 1 Unit | |
| Discharging pipe | L=4M DN50/DN25 | 1 Piece | |
| Shock-absorbing Tube | L=500mm DN50 | 2 Pieces | |
| Flange | 2.5MPaDN15 | 20 Pieces | |
| LPG Pump & Motor Specification | |||
| Pump Brand | Chinese brand lpg gas pump | ||
| Model | YQB15-5 | ||
| Medium | Liquid petroleum gas | ||
| Working pressure differential | ≤0.5Mpa | ||
| Inlet pressure | ≤1.0Mpa | ||
| Flow Speed | 15.5m3/h | ||
| Applied Power | 5.5kw | ||
| Inlet & Outlet Flange | 2”NPT / 2" NPT | ||
|
Revolution
|
780r/min | ||
| mass | 166kgs | ||
| Motor | Chinese brand | ||
| Specification | 7.5HP(5.5KW), Explosive Proof, Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
||
| LPG Cylinder electronic Filling Machines Specification | |||
| Brand | Chinese Kaiyuan Brand | ||
| Model | BCS-150 | ||
| Power supply available | 220V 50HZ | ||
| Rated power | 30W | ||
| Max weighting capacity | 150kg | ||
| Mini weighting capacity | 1kg | ||
| Measurement Precision | ±0.5% | ||
| Accuracy Level | Ⅲ | ||
| Certified Division value | 50g | ||
| Anti-explosion Rate | Exhibit II BT4 | ||
| Weighing station size | 535*425mm | ||
| Electronic scales No. | 1 set | ||
More pictures of hot sale 10tons lpg gas storage tank with refilling machine as below
2017s total new 10tons mobile skid lpg gas refilling station for sale
Mobile skid lpg gas refilling plant for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of bulk lpg gas storage tanks, lpg gas trailer, lpg gas delivery trucks, etc. in China since 2004s. With many years'development, OUR CLW brand pressure vessels have been exported to so many countries all over the world. Recently our CLW brand pressure vessels products pass the ASME certificate, and then our CLW lpg gas tank and lpg gas trailers could been exported to USA, Europe, Taiwan, etc. More information, please feel free to contact with Ms. Anita Deng.
