HOWO light duty 4-6m3 concrete mixer truck for sale, factory direct HOWO LHD 4*2 130hp diesel 4m3 truck mounted mixer
HOWO light duty 4-6m3 concrete mixer truck for sale, factory direct HOWO LHD 4*2 130hp diesel 4m3 truck mounted mixer
best price SINO TRUK HOWO light duty 4-6m3 concrete mixer truck for sale, factory direct HOWO LHD 4*2 yuchai 130hp diesel 4m3 truck mounted mixer truck
Concrete mixer truck manufactured by Chengli Special Automobile Co., Ltd. is just made up of the second class chassis and cement mixing transporting device,etc. The special devices of the mixer truck are PTO, the front and rear brackets of the mixing drum, reducer, hydraulic system, mixing drum, operation mechanism, cleaning system, etc. the working principal of the mixer truck is using the PTO take the power of the chassis, and also drive the variable stroke pump of the hydraulic system , changing the mechanical energy into hydraulic energy then transfer to the motor, and the motor drive the reducer, the reducer drive the mixing device, then mixing the cement, etc.
SINO TRUK HOWO light duty 4-6m3 mixer truck for sale
Best price and high quality HOWO RHD mixer truck for sale
The main technical parameters of hot sale SINO TRUK HOWO Light duty 4-6m3 concrete mixer truck manufactured by Chengli Special Automobile Co., Ltd. as below
| Main parameters | ||||
| Product name | HOWO light duty 6cubic meters mixer truck for sale | |||
| Total mass(Kg) | 16000 | Driving model | 4*2 | |
| Rated mass(Kg) | 8550 | Overall dimension(L*W*H)(mm) | 7350×2400×3650 | |
| Curb mass(Kg) | 7255 | Driver cab person | 3 | |
| approach/departure angle (°) | 20/17 | front/rear suspension(mm) | 1280/2270 | |
| Axle nos. | 2 | Wheelbase(mm) | 3800 | |
| Axle load(Kg) | 6000/10000 | Max speed(Km/h) | 80 | |
| Chassis main parameters | ||||
| Chassis model | ZZ1167G3815C1 | Overall dimension(mm) | 6430×2300×2720 | |
| Tyre specification | 9.00R20 | Tyre nos. | 6+1 | |
| Steel spring | 8/10+8 | Front tread(mm) | 1860 | |
| Fuel type | Diesel | Rear tread(mm) | 1670 | |
| Emission standard | Euro Ⅲ | Gearbox |
Wangliyang 6 speed gearbox
|
|
| Driver cab | HOWO light duty 2080mm one row and a half driver cab | |||
| Engine model | Manufacturer | Displacement (ml) | Power (Kw) | |
| YC4D130-33 | Yuchai diesel engine | 4214 | 96 | |
| The special devices of mixer drum mounted on dongfeng truck chassis | ||||
| Tank volume(m3) | 4cbm-6cbm | Mixer drum material | Q345 | |
| pump | USA Sauer Danfoss brand | Hydraulic motor | USA Sauer Danfoss brand | |
| Reducer | USA Sauer Danfoss brand | Residue rate | ≤1.0﹪ | |
| Water tank volume(L) | 250 | Water supplying way | air pressure type | |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of cement mixer trucks in China. With many years' development, Chengli Special Automobile Co., Ltd. could offer 3cbm-16cbm concrete mixer trucks, such as dongfeng brand mixer truck, HOWO brand cement mixer truck, FAW brand mixer truck, Foton Auman mixer truck, JAC mixer truck, etc. More information, please feel free to contact with Ms. Anita.
