SINO TRUK HOWO light duty 4*2 LHD mobile digital billboard LED advertising vehicle for sale,HOT SALE! HOWO LED truck
SINO TRUK HOWO light duty 4*2 LHD mobile digital billboard LED advertising vehicle for sale, HOT SALE!good price SINO TRUK HOWO P8 outdoor waterproof and shakeproof LED advertising truck
3 sides LED billboard truck,
PIXELS: 10mm/8mm/6mm(P10/P8/P6)
One side: 6.88
Sides(left + right): 6.88m2*2=13.76m2
Rear: 1.84m2
Stage: 10m2
SINO TRUK HOWO mobile LED truck, adopts SINO TRUK 1880mm driver cab, wangliyang 5 speed gearbox. 3360mm wheelbase, 2.4tons front axle/5tons rear axle, 7.00R16 radial tires, power steering, air brake, 120L oil tank, 170mm boom, xichai 87hp diesel Euro 4 engine etc.
The overall dimension(L*W*H) of SINO TURK HOWO Mobile LED truck:5995×2030×3050(mm), truck model: CLW5040XXCZ4.
1, the right side of the driver cab is with high quality P10/P8/P6 HD waterproof and shake-proof full color outdoor screen (screen area: 3840*1792=6.88m2),choose to install the side screen is with hydraulic lifting stage(stage area: 10m2, lifting height: 1.5m) and 4 sets manual/hydraulic outriggers.
2, the left side of the driver cab is with word roller light-box with automatically switching format advertisings; and the exterior with tempered glass or left and right sides with P10/P8/P6 screens
3, the rear part screen is with single color word screen (screen area: 1280*1440=1.84m2)
4, truck mounted diesel generator adopts high quality OUMA 8KW/15KW diesel generator.
5, truck trim: 5cm thickness composited steel box body frame, FRP material body, wooden floor, 4 sets of waterproof Audio, one set amplifier, intelligent Mechatronics controlling system, Circulating ventilation cooling system, safety intelligent Automatic switching system for inside and outside of the network, high ability Mute generator set, Gigabit flow Media control system.
Remark: the computer is with English words, English operation system and Software playback system.
If you're interested in our SINO TRUK HOWO mobile LED billboard truck, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
main technical parameters of hot sale SINO TRUK HOWO LED billboard truck manufactured by Chengli Special Automobile Co., Ltd. as below
| Main technical parameters | |||
| Product name | MOBILE LED billboard truck for sale | ||
| Total mass(Kg) | 4495 | Diesel generator | OUMA 8KW/15KW diesel generator |
| Curb mass(Kg) | 4300 | Overall dimension(L*W*H)(mm) | 5995×2040×2990 |
| Side screen area | 3840*1792=6.88m2 | Rear screen area | 1280*1440=1.84m2 |
| Seated person | 2 | Truck mounted computer | Full ENGLISH word Computer |
| Approach/departure angle(°) | 20/13 | Front/rear suspension(mm) | 1160/1475 |
| Axle nos. | 2 | Wheelbase(mm) | 3360 |
| Axle load(Kg) | 1790/2705 | Max speed(Km/h) | 90 |
| Truck chassis | |||
| Truck chassis model | Zz1047 | Manufacturer | SINO TRUK HOWO COMPANY |
| Tire specification | 7.00R16 | Tire nos. | 6+1 |
| Approach/departure angle(°) | 20/25 | Front tread(mm) | 1605 |
| Steel spring | 3/5+3 | Rear tread(mm) | 1520,1540 |
| Driver cab | 2 | Gearbox | 6 speed gearbox |
| Emission standard | Euro 3/4 | ||
| Engine model | Manufacturer | Displacement (ml) | Power (Kw) |
| 4DW93-84E4 | XICHAI | 2540 | 64KW/87hp |
More pictures of hot sale SINO TRUK HOWO 4*2 LHD mobile LED billboard advertising truck manufactured by Chengli Special Automobile Co., Ltd. as below.
SINO TRUK HOWO 4*2 LHD mobile LED truck for sale
high quality and best price SINO TURK HOWO LED truck with stage(stage area: 10m3)
HOT SALE! SINO TRUK HOWO 4*2 LED billboard advertising truck
More information, please contact with Ms. Anita.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
