new designed up-straight outdoor mobile LED advertising billboard semitrailer, best price mobile P4/P5/P6 LED trailer
HOT SALE! up-straight outdoor mobile LED advertising billboard semitrailer, factory direct sale best price mobile LED advertising trailer
Outdoor mobile LED displays screen advertising billboard trailer vehicle adopts P10 full color screen with high brightness, stable performance, impact resistance, etc. The LED trailer vehicle is with Stereo fidelity and Clear dynamic pictures. The trailer installs light control system adjusted the brightness of the screen freely. We can change the pictures and information quickly without any installation. The pictures are combining, realizing showing the multi-form, multi-vector and multi types information. The LED billboard trailer vehicle equips with TV turner, receiving the TV signal of CATV and TVB. Wide view, Strong visual shock and perfect communication effect.
If you're interested in our mobile LED billboard semitrailer, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
The detailed technical data for the 2017s model up-straight outdoor mobile LED advertisement vehicle as below.
1)driving part:
Scissor type hydraulic lifting platform and supporting system
Broadcasting system and Multimedia control system
Vehicle stability system
Current supply device, including intelligent timing on power system
| Overall dimension(L*W*H)(mm) | 7000*2500*3500mm | Material | 1.5mm thickness carbon steel |
| Truck body | Front axle + rear axle | Braking | Front wheel braking with braking lamp |
| Tyre specification | 750 | Mini turning diameter | ≤18000mm |
2)up-straight 360 degree rotation elevating platform and supporting system
| Hydraulic elevating system | |
| Elevating type | Up-straight 360 degree rotation |
| Platform dimension | 3200x750x400mm |
| Loading mass | 5500kgs |
| Supporting stability | 4 hydraulic outriggers, every outrigger with the loading mass of 5ton. |
| Screen folding controlling | Adopting hydraulic cylinders to uplift the front part of the screen, and show the whole full screen; with 360 degree rotation |
| Minimum visibility distance | 5m |
| Lifting range | 400mm-2400mm |
| horizontal view angle | 110(±55) degree |
| vertical angle of view | 400mm-2400mm |
3) LED screen (P10)
| Screen dimension | 4800x1600mm(4800*3200mm two screen tog) | Module dimension | 160x160mm |
| tube core | R/G/B:Taiwan wafer | Pixel dot spacing | 10mm |
| intensity | ≥6500cd/㎡ | Pixel density | 10000 point/㎡ |
| Max power | ≤1000W/㎡ | Screen lifetime | >100,000 hours |
4) broadcasting system and Multimedia control system
LED Industrial Personal Computer |
Overall dimension:410mm(H)x210mm(W)x60mm(D),9.2inch touch screen, | ||
| device:Intel low power consumption Dual Core 1.8G 4tCPU,internal storage:standard configuration DDR3 2G, memory:SSD32G Solid State Disk； | |||
| Operation system: supporting DOS,WINCE,LINUX,XPE,XP | |||
| Power amplifier | 1 unit | Auto | 120KWX2 |
The trailer type outdoor mobile LED full color screen advertising vehicle is withour any power itself, driven by any exterior power. And the dimension of the outdoor mobile LED full color screen advertising trailer vehicle can be changed according to customer’s requirements.
More pictures of hot sale Mobile LED advertising billboard truck as below
mobile LED advertising billboard truck for sale
high quality and best price CLW brand mobile LED advertising semitrailer for sale
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
