new ISUZU 4*2 LHD mobile LED billboard advertising truck with 3 sides P6 LED screen, hot sale LED colorful screen truck
new ISUZU 4*2 LHD mobile LED billboard advertising truck with 3 sides P6 LED screen, hot sale LED vehicle
the main technical parameters of Mobile LED screen mounted on ISUZU truck chassis
3 sides LED screen billboard for ISUZU truck chassis
PIXELS: 6mm(P6)
One side: 3840*1728=6.65㎡
Sides(left + right): 6.65m2*2=13.3㎡
Rear: 1280*1440=1.84㎡
The overall dimension(L*W*H) of ISUZU Mobile LED truck: 5995*2040*2990(mm),
1, Both left side and right side is with high quality P6 HD waterproof and shake-proof full color outdoor LED screen (screen area: 3840*1792=6.88m2); and both sides screens can be flipped up-down;
2, 4* hydraulic outriggers to keep the LED truck stable.
3, the back side is with high quality P6 HD waterproof and shake-proof full color outdoor LED screen (screen area: 1280*1440=1.84m2).
4, truck mounted diesel generator adopts high quality 15KW diesel generator unit( oil consumption: 3-4L/hour).
5, truck trim: 5cm thickness composited steel box body frame, FRP material body, wooden floor,
6, 4 sets of waterproof Audio, one set amplifier, intelligent Mechatronics controlling system, Circulating ventilation cooling system, safety intelligent Automatic switching system for inside and outside of the network, high ability Mute generator set, Gigabit flow Media control system.
Remark: the computer is with English words, English operation system and Software playback system
If you're interested in our ISUZU Mobile LED advertising truck, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
main technical parameters of hot sale ISUZU Euro 5 mobile LED advertising truck as below
| Main technical parameters | |||
| Product name | ISUZU MOBILE LED billboard truck for sale | Product model | CLW5040XXCQL5 |
| Total mass(Kg) | 4495(Kg) | Diesel generator | OUMA 8KW/15KW diesel generator |
| Curb mass(Kg) | 4365(Kg) | Overall dimension(L*W*H)(mm) | 5995×2040×2990(mm) |
| Side screen area P6 | 3840*1728=6.65m2 | Rear screen area | 1280*1440=1.84m2 |
| Seated person | 2 | Truck mounted computer | Full ENGLISH word Computer |
| Approach/departure angle(°) | 24/12(°) | Front/rear suspension(mm) | 1015/1620(mm) |
| Axle nos. | 2 | Wheelbase(mm) | 3360 |
| Axle load(Kg) | 1805/2690 | Max speed(Km/h) | 98 |
| Truck chassis | |||
| Truck chassis model | QL1040A6HAY | Manufacturer | ISUZU company |
| Tire specification | 7.00R16 8PR | Tire nos. | 6+1 |
| Steel spring | 3/3+2 | Front/rear tread(mm) | 1377/1425 |
| Driver cab | ISUZU 100P single row luxurious driver cab with air conditioner and power steering | Brake | Oil cut brake with vacuum booster |
| Fuel type | Diesel | Gearbox | ISUZU MSB gearbox |
| Emission standard | Euro 5 | ||
| Engine model | Manufacturer | Displacement (ml) | Power (Kw) |
| 4KH1CN5LS | ISUZU | 2999 | 72 |
More pictures of hot sale ISUZU 4*2 LHD mobile LED advertising billboard truck as below
HOT SALE! ISUZU brand mobile LED advertising truck with three sides LED screen
More information, please contact Ms. Anita.
Whatsapp/Wechat: + 13329899995
Skype: truck0011
QQ: 504873236
