15tons skid lpg gas station with double weighting scales for sale, factory sale best price 15tons mobile skid lpg plant
CLW Brand 15tons skid lpg gas station with double digital weighting scales for sale, factory sale best price 15tons mobile skid-mounted lpg gas refilling station for gas cylinders
Chengli Special Automobile Co., Ltd. can be customixed the skid lpg gas filling station with 2 sets of electronic scales and filling nozzles for gas cylinders. That is to say, this skid lpg gas refilling station can fill 2 sets of gas cylinders at one time. And also print ticket for clients. At the same time, this 15 tons mobile skid-mounted lpg gas refilling plant equipps with double lpg gas pump and motor.
The finished full set of skid-mounted lpg gas plant is well-appinted, installed with lpg gas vane pump, motor, electronic scale etc. The clients can use it to fill gas cylinders directly. And at the same time, we can design and manufacture ASME standard ones. The mobile skid-mounted lpg gas plant is ask for higher installing quality. more and more clients choose our CLW brand company, that is to say our CLW brand lpg gas pressure vessels gain acceptance at home and overseas.
If you're interested in our 15tons skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of hot sale CLW brand 15tons skid lpg gas station for gas cylinders as below.
main technical parameters of hot sale CLW brand 15tons skid lpg gas station manufactured by Chengli Special Automobile Co., Ltd. as below.
| 32 CBM skid-mounted lpg gas filling plant DIMENSIONS | |||
| Volume of Tank | 32CBM | ||
| Loading capacity | 15tons | ||
| Tank Weight | 7110kg | ||
| Thickness of Shell (mm) | 12 mm | ||
| Thickness of Endplate (mm) | 14 mm | ||
| Tank Diameter (mm) | 2300 mm | ||
| External Dimensions (mm) (length x width x height) | 8158 x 2324 x 2914 mm | ||
| Material of Tank and Main Pressure Parts | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( Propane) | ||
| Design Pressure | 1.77 MPa | ||
| Corrosion Allowance | 1 mm | ||
| Medium Density | 420 kg/ cbm-550kg/cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification | Quantity | |
| Discharge Pipe | DN50 | 1 | |
| Inflow Pipe | DN50 | 1 | |
| Outlet | DN50 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Manhole | DN450 | 1 | |
| Drain Hole | DN50 | 1 | |
| Electronic LPG Filling Machine | Can fill 1kg to 150kg gas cylinder | 1 | |
| Lpg gas compressor | Surcharging and filling lpg gas truck | Choose to install, 1 set | |
|
Main accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. Skid Parts List will be show in separated page below. |
|||
Main parameters of lpg gas pump & motor and electronic scale as below
| LPG Pump & Motor Specification | |||
| Pump Brand | Chinese brand lpg gas pump | ||
| Model | YQB15-5 | ||
| Medium | Liquid petroleum gas | ||
| Working pressure differential | ≤0.5Mpa | ||
| Inlet pressure | ≤1.0Mpa | ||
| Flow Speed | 15.5m3/h | ||
| Applied Power | 5.5kw | ||
| Inlet & Outlet Flange | 2”NPT / 2" NPT | ||
|
Revolution
|
780r/min | ||
| mass | 166kgs | ||
| Motor | Chinese brand | ||
| Specification | 7.5HP(5.5KW), Explosive Proof, Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
||
| LPG Cylinder electronic Filling Machines Specification | |||
| Brand | Chinese Kaiyuan Brand | ||
| Model | BCS-150 | ||
| Power supply available | 220V 50HZ | ||
| Rated power | 30W | ||
| Max weighting capacity | 150kg | ||
| Mini weighting capacity | 1kg | ||
| Measurement Precision | ±0.5% | ||
| Accuracy Level | Ⅲ | ||
| Certified Division value | 50g | ||
| Anti-explosion Rate | Exhibit II BT4 | ||
| Weighing station size | 535*425mm | ||
| Electronic scales No. | 2 sets | ||
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of bulk lpg gas storage tanks, lpg gas trailer, lpg gas delivery trucks, etc. in China since 2004s. With many years'development, OUR CLW brand pressure vessels have been exported to so many countries all over the world. Recently our CLW brand pressure vessels products pass the ASME certificate, and then our CLW lpg gas tank and lpg gas trailers could been exported to USA, Europe, Taiwan, etc. More information, please feel free to contact with Ms. Anita Deng.
