China smallest P8 mobile LED advertising truck for sale, Factory sale Chang'an 65KW gasoline outdoor mobile LED truck
HOT SALE! China smallest P8 mobile LED advertising truck for sale, Factory sale best price Chang'an 65KW gasoline outdoor mobile LED billboard advertising truck
Hot sale Euro 5 gasoline 88hp Chang’an brand mini mobile LED digital advertising truck for sale
2/3 sides LED billboard truck,
PIXELS: 8mm(P8)
One side: 2304*1408＝3.14
Two Sides(left + right): 3.14*2=8.28m2
Back back: 960*1280＝1.64m2
The overall dimension(L*W*H) of Chang’an Mobile LED truck:4750,5100 * 1900 * 2700 (mm),
1, the right side of the driver cab is with high quality P6 HD waterproof and shake-proof full color outdoor screen (screen area: 2304*1408＝3.14㎡),choose to install the side screen is with hydraulic lifting stage( lifting height: 1.5m) and 4 sets manual/hydraulic outriggers.
2, the left side of the driver cab is with word roller light-box with automatically switching format advertisements; and the exterior with tempered glass or left and right sides with P6 screens
3, the rear part screen is with single color word screen (screen area: 960*1280＝1.64㎡)
4, truck mounted diesel generator adopts high quality YIHU 9KW/6.5KW gasoline generator unit.
5, truck trim: 5cm thickness composited steel box body frame, FRP material body, wooden floor, 4 sets of waterproof Audio, one set amplifier, intelligent Mechatronics controlling system, Circulating ventilation cooling system, safety intelligent Automatic switching system for inside and outside of the network, high ability Mute generator set, Gigabit flow Media control system.
Remark: the computer is with English words, English operation system and Software playback system.
If you're interested in our Chang'an mobile LED advertising truck, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of hot sale Chang'an smallest 88hp gasoline P8 outdoor LED advertising truck as below
Chang'an mobile LED advertising truck for sale
hot sale! high quality and competitive price China smallest P8 mobile LED advertising truck
cheapest price Chang'an 4*2 LHD 88hp gasoline mobile LED advertising truck for sale
main technical parameters of hot sale Chang'an 88hp gasoline P8 mobile LED advertising truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Main technical parameters | |||
| Product name | Chang’an MOBILE LED billboard truck for sale | ||
| Total mass(Kg) | 2840 | Diesel generator | Yihu 6.5KW/9KW gasoline generator unit |
| Curb mass(Kg) | 2360(Kg) | Overall dimension(L*W*H)(mm) | 4750,5100 * 1900 * 2700(mm) |
| Side screen area | 2304*1408＝3.14㎡ | Rear screen area | 960*1280＝1.64m2 |
| Seated person | 2 | Truck mounted computer | Full ENGLISH word Computer |
| Approach/departure angle(°) | 40/20(°) | Front/rear suspension(mm) | 635/1415,635/1475(mm) |
| Axle nos. | 2 | Wheelbase(mm) | 2700 |
| Axle load(Kg) | 1420/1420 | Max speed(Km/h) | 90 |
| Truck chassis | |||
| Truck chassis model | SC1031GDD52 | Manufacturer | Chang’an company |
| Tire specification | 165R14LT | Tire nos. | 4+1 |
| Front tread(mm) | 1360,1372 | Rear tread(mm) | 1300 |
| Steel spring | -/5,4/5 | Gearbox | 5 speed gearbox |
| Emission standard | Euro Ⅴ | ||
| Engine model | Manufacturer | Displacement (ml) | Power (Kw) |
| DK12-10 | Chang’an automobiles | 1240 | 65KW/88HP |
More information, please feel free to contact Ms. Anita.
Whatsapp/Wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
