Bottom price 50m3 skid lpg gas refilling station for cars and taxi, factory sale mobile skid lpg tank with lpg dispenser
Skid system lpg with automobile lpg dispenser can fill not only the domestic gas cylinders, but also automobiles, mainly city buses, just to adjust the nozzles.
There are various models available with LPG storage tank capacity ranging from 3000 Liters to 120000 Liters and with the choice of single or double nozzle LPG dispensers.
The unit comes with all safety features as per norms.
The unit is easy to install and operate and much cheaper as compared to other plants.
2.Standard features of skid lpg gas plants as below
1) Minimum Installation Area.
2) Self Filling System.
3) Available for 24hrs.
4) Lowest Installation Cost.
5) Portable System.
3．Technical data
1) Delivered product: LPG
2) Temperature range: -20℃～50℃
3) Design pressure:1.8Mpa
4) Flow rate: depending on the type of pump installed
5) Tension: 380V/50Hz
4. LPG Skid Equipment
1) LPG storage tank
2) LPG pump
3) LPG ball valves
4) other equipments
If you're interested in our skid lpg gas refilling station, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Recently, we Chengli Special Automobile Co., Ltd. Received an order of 3 units of mobile skid-mounted lpg gas station with auto lpg gas dispenser(with double filling nozzles) for NIPCO GAS from Nigeria.
More pictures of hot sale 45m3 skid lpg gas stations with auto lpg gas dispenser( double filling nozzles) for cars as below
skid lpg gas station with auto lpg gas dispenser(with double filling nozzles)
HOT SALE! Mobile skid lpg gas station with auto lpg gas dispenser
Factory sale best price CLW brand skid lpg gas refilling station for cars
Main technical parameters of hot sale 50m3 skid lpg gas station with auto lpg gas dispenser as below
| 50 CBM LPG TANK DIMENSIONS | |||
| Volume of Tank | 50,000L | ||
| Filling Weight | 20,000kgs-25000kgs(lpg gas propane density of 420-500kg/cbm) | ||
| Tank Weight | 10640 | ||
| Thickness of Shell (mm) | 14mm | ||
| Thickness of Endplate (mm) | 16mm | ||
| Tank Diameter (mm) | 2700 mm | ||
| Tank Dimensions (mm) (length x width x height) | 9182*2728*3318mm | ||
| External Dimensions (mm) (length x width x height) | Approximate 12.2*2.4*3.8(m) | ||
| Material of Tank | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( Propane) | ||
| Design Pressure | 1.77 MPa | ||
| Corrosion Allowance | 1 mm | ||
| Medium Density | 420-520 kg/ cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification/ mm | Quantity | |
| Discharge Pipe | DN50 | 1 | |
| Inflow Pipe | DN50 | 1 | |
| Outlet | DN50 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Manhole | DN450 | 1 | |
| Drain Hole | DN50 | 1 | |
| Other accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. | |||
| LPG Skid Parts list | |||
| Item | Model Number | Quantity | |
| LPG Tanker | 50,000L | 1 piece | |
| Pump | 2" inlet & 2" outlet | 1 Piece | |
| Explosive-proof Motor | 380V with 220V adapter | 1 Piece | |
| auto lpg gas dispenser | with double filling nozzles for cars, | 1pieces | |
| Pipes | / | ||
| Cut-off Valve | J41N-40 DN50 | ||
| J41N-40 DN15 | |||
| Safety Valve | A42F-25 DN50 | ||
| Pipe Safety Valve | A21F-25 DN15 | ||
| Level Gauge | Float ball type | ||
| Discharging pipe | L=4M DN50/DN25 | ||
| Shock-absorbing Tube | L=500mm DN50 | ||
| Flange | 2.5MPaDN15 | ||
| LPG Pump & Motor Specification | |||
| Pump Brand | Chinese brand lpg gas pump | ||
| Model | YQB15-5 | ||
| Medium | Liquid petroleum gas | ||
| Working pressure differential | ≤0.5Mpa | ||
| Inlet pressure | ≤1.0Mpa | ||
| Flow Speed | 15.5m3/h | ||
| Applied Power | 5.5kw | ||
| Inlet & Outlet Flange | 2”NPT / 2" NPT | ||
|
Revolution
|
780r/min | ||
| mass | 166kgs | ||
| Motor | Chinese brand | ||
| Specification | 7.5HP(5.5KW), Explosive Proof, Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
||
More information, please feel free to contact Ms. Anita.
Whatsapp/Mob./Wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
