Factory sale cheaper price 25m3 skid lpg gas refilling station with auto lpg gas dispenser(with 2 nozzles) for cars
Factory sale cheaper price 25m3 skid lpg gas refilling station with auto lpg gas dispenser(with double filling nozzles) for automobiles
Nowadays, more and more clients choose to purchase mobile skid lpg gas plant for their lpg gas plant business. We Chengli Special Automobile Co., Ltd. can customize skid lpg gas plant with digital scales for filling domestic gas cylinders or automatic lpg gas dispenser for automobiles. And clients can choose 1/2/3/4/5 digital scales install on the skid lpg gas plant upon request, or even. And they can also choose install lpg gas dispenser with 1/2/3/4/5 nozzles for automobiles.
skid system lpg with automobile lpg gas dispenser is used for refilling of liquified petrol gas (LPG). As a major equipment of the LPG station, it is equipped with high-accuracy positive displacement flowmeter,microcomputer control, large LCD counter and various control valves and protection devices assuring operation safety.With advanced manufacturing technique, the dispenser has reliable quality and excellent performance with characteristics of precise ration, easy maintainance and centralized control. Each gun connects to an independent flow and metering system which prevents interference.
If you're interested in our skid lpg gas refilling station, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
More pictures of 25,000Liters skid lpg gas station with auto lpg gas dispenser for filling automobiles as below
skid lpg gas refilling station with auto lpg gas dispenser for sale
main technical parameters of hot sale 25,000Liters skid lpg gas tank with lpg gas dispenser as below
| 25,000L LPG TANK DIMENSIONS | |||
| Volume of Tank | 25m3 | ||
| Filling capacity | 12.5tons | ||
| Tank Weight | 6020kgs | ||
| Thickness of Shell (mm) | 12mm | ||
| Thickness of Endplate (mm) | 14mm | ||
| Tank Diameter (mm) | 2200 mm | ||
| Tank Dimensions (mm) (length x width x height) | 7008*2224*2814mm | ||
| Material of Tank | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( Propane) | ||
| Design Pressure | 1.77 MPa | ||
| Corrosion Allowance | 1 mm | ||
| Medium Density | 420-590 kg/ cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification/ mm | Quantity | |
| Discharge Pipe | DN50 | 1 | |
| Inflow Pipe | DN50 | 1 | |
| Outlet | DN50 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Manhole | DN450 | 1 | |
| Drain Hole | DN50 | 1 | |
| Other accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. | |||
| LPG Skid Parts list | ||
| Item | Model Number | Quantity |
| LPG Tanker | 25,000L | 1 piece |
| Pump | 2" inlet & 2" outlet | 1 Piece |
| Explosive-proof Motor | 380V with 220V adapter | 1 Piece |
| Digital weighting scales | Single or double filling nozzles | 2pieces |
| Pipes | / | 1 Sets |
| Cut-off Valve | J41N-40 DN50 | 25 Pieces |
| J41N-40 DN15 | 10 Pieces | |
| Safety Valve | A42F-25 DN50 | 1 Piece |
| Pipe Safety Valve | A21F-25 DN15 | 1 Piece |
| Level Gauge | Float ball type | 1 Unit |
| Discharging pipe | L=4M DN50/DN25 | 1 Piece |
| Shock-absorbing Tube | L=500mm DN50 | 2 Pieces |
| Flange | 2.5MPaDN15 | 20 Pieces |
| LPG Pump & Motor Specification | ||
| Pump Brand | Chinese brand lpg gas pump | |
| Model | YQB15-5 | |
| Medium | Liquid petroleum gas | |
| Working pressure differential | ≤0.5Mpa | |
| Inlet pressure | ≤1.0Mpa | |
| Flow Speed | 15.5m3/h | |
| Applied Power | 5.5kw | |
| Inlet & Outlet Flange | 2”NPT / 2" NPT | |
|
Revolution
|
780r/min | |
| mass | 166kgs | |
| Motor | Chinese brand | |
| Specification | 7.5HP(5.5KW), Explosive Proof, Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
|
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. Our CLW lpg gas pressure vessels(lpg gas storage tank, lpg gas trailer, lpg gas truck, lpg gas dispensing truck, skid lpg gas filling plant) have been exported to so many countries all over the world. And to meet the needs of the international market, Chengli Special Automoile Co., Ltd. lpg gas pressure vessel factory design and manufacture lpg gas dispensing truck and skid lpg gas filling plant. More information, please feel free to contact Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
