customized mobile skid propane gas refilling station with 4 digital weighting scales for sale, skid lpg gas plant
customized mobile skid propane gas refilling station with 4 digital weighting scales for sale, factory sale high quality and low price skid lpg gas plant for filling gas cylinders
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With mnay years' development, Chengli Group can manufacture and sell lpg gas storage tank, lpg gas tank trailer, lpg gas truck, skid lpg gas refilling plant, etc. And the mobile skid-mounted lpg gas filling stations are from 5,000L to 120,000L. More information, please feel free to contact with Ms. Anita.
The finished full set of skid-mounted lpg gas plant is well-appinted, installed with lpg gas vane pump, motor, electronic scale etc. The clients can use it to fill gas cylinders directly. And at the same time, we can design and manufacture ASME standard ones. The mobile skid-mounted lpg gas plant is ask for higher installing quality. more and more clients choose our CLW brand company, that is to say our CLW brand lpg gas pressure vessels gain acceptance at home and overseas.
If you're interested in our mobile skid-mounted lpg gas refilling station, please feel free to send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
More pictures of hot sale 20m3 skid lpg gas refilling station with 4 digital weighting scales for gas cylinders customized for client as below.
HOT SALE! Mobile skid lpg gas station with digital weighting scales for sale
skid lpg gas refilling station with 4 digital scales for gas cylinders for sale
2017s best seller skid lpg gas refilling station for sale
Main technical parameters of hot sale 20M3 mobile skid lpg gas refilling plant with 4 scales as below
| LPG Skid Parts list | ||||||
| Item | Model Number | Quantity | ||||
| LPG Tanker | 20,000L | 1 piece | ||||
| Pump | 2" inlet & 2" outlet | 2Piece | ||||
| Explosive-proof Motor | 380V with 220V adapter | 2Piece | ||||
| Electronic Weighting Scale with filling nozzles | Can fill 1kg to 150kg LPG cylinders | 4pieces | ||||
| Pipes | / | 1 Sets | ||||
| Cut-off Valve | J41N-40 DN50 | 25 Pieces | ||||
| J41N-40 DN15 | 10 Pieces | |||||
| Safety Valve | A42F-25 DN50 | 1 Piece | ||||
| Pipe Safety Valve | A21F-25 DN15 | 1 Piece | ||||
| Level Gauge | Float ball type | 1 Unit | ||||
| Discharging pipe | L=4M DN50/DN25 | 1 Piece | ||||
| Shock-absorbing Tube | L=500mm DN50 | 2 Pieces | ||||
| Flange | 2.5MPaDN15 | 20 Pieces | ||||
| LPG Pump & Motor Specification | ||||||
| Pump Brand | Chinese brand lpg gas pump | |||||
| Model | YQB15-5 | |||||
| Medium | Liquid petroleum gas | |||||
| Working pressure differential | ≤0.5Mpa | |||||
| Inlet pressure | ≤1.0Mpa | |||||
| Flow Speed | 15.5m3/h | |||||
| Applied Power | 5.5kw | |||||
| Inlet & Outlet Flange | 2”NPT / 2" NPT | |||||
|
Revolution
|
780r/min | |||||
| mass | 166kgs | |||||
| Motor | Chinese brand | |||||
| Specification | 7.5HP(5.5KW), Explosive Proof, Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
|||||
| LPG Cylinder electronic Filling Machines Specification | ||||||
| Brand | Chinese Kaiyuan Brand | |||||
| Model | BCS-150 | |||||
| Power supply available | 220V 50HZ | |||||
| Rated power | 30W | |||||
| Max weighting capacity | 150kg | |||||
| Mini weighting capacity | 1kg | |||||
| Measurement Precision | ±0.5% | |||||
| Accuracy Level | Ⅲ | |||||
| Certified Division value | 50g | |||||
| Anti-explosion Rate | Exhibit II BT4 | |||||
| Weighing station size | 535*425mm | |||||
| Electronic scales No. | 4 | |||||
| Main parts of LPG Tank | ||||||
| Item | Specification/ mm | Quantity | ||||
| Discharge Pipe | DN50 | 1 | ||||
| Inflow Pipe | DN50 | 1 | ||||
| Outlet | DN50 | 1 | ||||
| Gas phase balance pipes | DN50 | 2 | ||||
| Manhole | DN450 | 1 | ||||
| Drain Hole | DN50 | 1 | ||||
| Other accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. | ||||||
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. Our CLW lpg gas pressure vessels(lpg gas storage tank, lpg gas trailer, lpg gas truck, lpg gas dispensing truck, skid lpg gas filling plant) have been exported to so many countries all over the world. And to meet the needs of the international market, Chengli Special Automoile Co., Ltd. lpg gas pressure vessel factory design and manufacture lpg gas dispensing truck and skid lpg gas filling plant. And last year, we design and produce the first skid lpg gas filling plant for Nigerian client with 40,000L. The client was satisified with the skid lpg gas tank for refilling gas cylinders.
More information, please feel free to contact with Ms. Anita.
