Factory sale best price 56cbm propane gas transported trailer, HOT SALE! high quality and cheaper price lpg tank trailer
Factory sale best price 56cbm propane gas transported trailer, HOT SALE! high quality and cheaper price lpg tank trailer
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton BPW bridges(FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.
The LPG tanker semi-trailer is line with the GB150-1998, <<Supervision Regulation On Safety Technology for Pressure Vessel>>, <<Regulation of Safety Supervision for Liquefied Gas Tank Car>>.
The data above is for your reference, we reserve the right of technical alteration/change for better improvement without prior notice. The detail is line with the contract.
If you're interested in our lpg gas tank trailer, please feel free to contact with Ms. Anita. Email: truck0011@163.com or Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of hot sale CLW brand 56m3 bulk lpg gas tank trailer as below
Factory sale best price CLW brand 56m3 bulk lpg gas tank trailer
main technical parameters of hot sale CLW brand 56,000Liters bulk lpg gas tank trailer as below.
| Basic information | ||
| Truck trailer model | CLW9408GYQ | |
| Wheelbase | mm | 6800+1310+1310 |
| Rear track | mm | 1840/1840/1840 |
| Total mass | T | 40 |
| Truck size | m | 12900×2500×3980 |
| Curb weight | T | 16.48 |
| Loading mass | T | 20T to 22T |
| Steel spring NO | Pcs | -/7/7/7 |
| Axles brand | / | BPW |
| Axles NO | Pcs | 3 |
| Axles loading | kg | 13000 |
| Legs brand | / | Jost |
| Legs loading | kg | 28000 |
| Tyres No | Pcs | 12+1 |
| Tyre type | / | 12 tubeless |
| Tyre carrier | Pcs | 2 spare tyre carrier |
| Frame | / | Carbon steel |
| King ping | / | #50 |
| Brakes | / | yes |
| Dust guard | dust guard of rubber | |
| Tanker volume | L | 56,000 |
| Tanker material | / | Carbon stel Q345R |
| Tanker thickness | mm | 12.5 |
| Tanker diameter | mm | 2450 |
| Tanker design pressure | Mpa | 1.77 |
| Water test pressure | Mpa | 2.22 |
| Tanker temprature | -19 to 50 | |
| Painting | Chassis paint of gray color (possible another color by future request) | |
|
1.Single out the solution 2.Bilateral Handling 3.Double valve box 4.Single Kit 9.Fire extinguishers 10.Anti-static grounding tape |
||
| Seller offer certificate | ||
| 1 | Material test (Q345 no scratch, Pressure values | |
| 2 | X-rayinspectionfor bubbles, sand | |
| 3 | Hydrostatic test certificate | |
| 4 | Ultra sonic test certificate | |
| 5 | Heat Treatment certificate | |
| 6 | Material list and certificate of pressure retaining part | |
| 7 | Certificate of material used for fabrication of tank | |
| 8 | Welding joints should be x-rayed as per rules and regulations. | |
| 9 | Illustration of Welding joints location | |
| 10 | Technical drawings of tank | |
| Payment term | T/T(30% advance.before shipment,70% balance) | |
| Warranty | 12months | |
| FOB shanghai price | .00USD | |
| CIF manila price | .00USD | |
| Delivery time | We can offer you in within 30days now . | |
The main techncial parameters of CLW brand lpg gas tank trailers manufactured by Chengli Special Automobile Co., Ltd. as below.
- Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 100 cubic optional.
- Chengli pressure components of the productIion materials, size and weld quality, operation quality, installation quality, safety valves and shut off valves devices and accessories within the strict qualification,inspection , test .the tank materials on physical and chemical tests such as: mechanical properties and chemical composition.
- the tank welded joints, welding line , tank head, the pressure of the geometric location of each component through rigorous X-ray non-destructive testing and magnetic particle testing inspection.
- seal on the product, pressure, and those who can affect the operation of product safety testing various technical indicators.
- A, B Class 100% ray weld inspection, II level qualified
- C, D Class welds 100% magnetic particle inspection, I level qualified
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
